Sensor 24424110
| No. | Part Name | Part Number | Qty | Description |
| 1 | Oil pan | 20702520 | 1 | |
| 2 | Magnetic plug | 20571854 | 1 | |
| 3 | Sealing ring | 20579690 | 1 | |
| 4 | Connection pipe | 20462497 | 1 | |
| 5 | Sealing ring | 20555696 | 1 | (421629) |
| 6 | Flange screw | 946440 | 2 | |
| 7 | Bracket | 3807087 | 1 | |
| 8 | Flange lock nut | 977938 | 2 | |
| 9 | Hose | 3831383 | 1 | |
| 10 | Hose clamp | 994561 | 2 | |
| 11 | Flange screw | 945444 | 2 | |
| 12 | Oil filler pipe | 20808091 | 1 | |
| 13 | Oil filler cap | 20807510 | 1 | |
| 14 | Rubber washer | 20365079 | 1 | |
| 15 | Dipstick | 21839748 | 1 | |
| 16 | O-ring | 949187 | 2 | |
| 17 | Pipe | 20724256 | 1 | |
| 18 | O-ring | 949656 | 1 | |
| 19 | Pipe | 3807085 | 1 | |
| 20 | Six point socket scr | 975371 | 1 | |
| 21 | Retainer | 20586869 | 1 | |
| 22 | Flange screw | 966378 | 4 | |
| 23 | O-ring | 20586720 | 1 | |
| 24 | Sensor | 24424110 | 1 | Replaced by sender 21042447. |
| 25 | O-ring | 944126 | 1 | |
| 26 | Flange screw | 946934 | 2 | |
| 27 | Flange screw | 948356 | 3 | |
| 28 | Retainer | 20700754 | 3 | |
| 29 | Sealing strip | 20532272 | 1 | |
| 30 | Flange screw | 20463185 | 16 | Replaced by 20739547 |
| 31 | Oil pump | 8170261 | 1 | |
| 32 | Suction pipe | 8170878 | 1 | |
| 33 | Sealing ring | 465784 | 1 | |
| 34 | Flange screw | 965180 | 3 | |
| 35 | Flange screw | 968842 | 1 | L=110mm |
| 36 | Flange screw | 471734 | 4 | |
| 37 | Pressure pipe | 20411298 | 1 | |
| 40 | Sealing ring | 8170558 | 1 | |
| 41 | Piston cooling jet | 3155151 | 6 | |
| 42 | Flange screw | 966378 | 6 | |
| 43 | Nozzle, transmission | 8170583 | 1 | |
| 44 | Screw | 471586 | 1 | |
| 45 | Control valve | 21452473 | 1 | Replaced by 21596642 |
| 46 | Sealing ring | 20526428 | 1 | |
| 47 | Outlet pipe | 20734464 | 1 | |
| 48 | Flange screw | 3165142 | 2 | |
| 49 | Sealing ring | 1677370 | 2 | |
| 50 | Flange screw | 966378 | 1 |
| Item | Part Name | Part No. |
| 24 | Sensor 24424110 | 24424110 |
| Details | |
| Engine model | TAD1250VE, TAD1251VE, TAD1252VE TAD1640GE, TAD1641GE, TAD1642GE, TAD1650GE, TAD1651GE, TWD1643GE, TWD1652GE, TWD1653GE, TWD1663GE TAD1641VE, TAD1642VE, TAD1643VE, TAD1660VE, TAD1661VE, TAD1662VE, TAD1640VE-B, TAD1641VE-B, TAD1642VE-B TAD1660VE, TAD1661VE, TAD1662VE, TAD1640VE-B, TAD1641VE-B, TAD1642VE-B TAD940GE, TAD941GE TAD940VE, TAD941VE, TAD942VE TAD940VE, TAD941VE, TAD942VE, TAD943VE TAD950VE, TAD951VE, TAD952VE TWD1643GE, TWD1652GE, TWD1653GE, TWD1663GE |
| Application | Contacts and Sensors. SN -2016080035 Lubricating Oil System with Aluminum Sump Lubricating System Lubricating System. SN7009159770- Lubricating SystemSN7009167424- |
| Specification | |
| Descriptions | Replaced by 21042447 Replaced by sender 21042447. |
