V-belt 978777
| No. | Part Name | Part Number | Qty | Description |
| 1 | Coolant pump | 866583 | 1 | |
| 1 | Coolant pump | 3803208 | 1 | |
| 2 | Gasket | 423127 | 1 | |
| 3 | Hexagon screw | 955542 | 6 | |
| 4 | Hexagon screw | 940162 | 2 | MO-XXXXX/105194 |
| 5 | Spring washer | 942336 | 8 | |
| 6 | Spring pin | 951973 | 2 | |
| 7 | Thermostat housing | 1545161 | 1 | |
| 8 | Gasket | 1545244 | 1 | |
| 9 | Sealing ring | 1544710 | 1 | |
| 10 | Thermostat | 8149186 | 1 | 86°C |
| 11 | Sealing ring | 1544410 | 1 | |
| 12 | O-ring | 925074 | 1 | |
| 13 | Plug | 960632 | 2 | |
| 14 | Gasket | 947624 | 2 | |
| 15 | Thermostat housing | 862337 | 1 | |
| 16 | Hexagon screw | 942547 | 6 | |
| 17 | Plug | 479977 | 1 | |
| 18 | Flange | 843908 | 1 | |
| 19 | Plug | 479977 | 1 | |
| 20 | Connecting pipe | 847537 | 1 | |
| 21 | O-ring | 975675 | 1 | |
| 22 | Hexagon screw | 940135 | 3 | |
| 23 | Spring washer | 941907 | 3 | |
| 24 | Spring washer | 942336 | 6 | |
| 25 | Nipple | 479954 | 1 | (190130) |
| 26 | Nipple | 192555 | 1 | SN-XXXXXXXXXX/262417 |
| 27 | Elbow nipple | 942758 | 1 | SNXXXXXXXXXX/262418- |
| 28 | Sealing ring | 469477 | 1 | Replaced by 842427, 842428, 842429, 842423, 411710., Late type (424345) |
| 29 | Hexagon screw | 940135 | 2 | |
| 30 | Spring washer | 941907 | 2 | |
| 31 | Gasket | 423138 | 1 | |
| 32 | Pipe elbow, pipe | 423137 | 1 | For turbo with rotor 842832., (822430) |
| 33 | Plug | 479977 | 1 | |
| 34 | Hexagon screw | 955537 | 1 | |
| 34 | Hexagon screw | 955540 | 1 | MOXXXXX/105195- |
| 35 | Spring washer | 942336 | 2 | |
| 37 | V-belt | 978777 | 1 | |
| 38 | Pulley, 2 grooves | 843599 | 1 | For turbo with rotor 842063. |
| 39 | Hexagon screw | 940186 | 4 | |
| 40 | Spring washer | 941907 | 4 |
| Item | Part Name | Part No. |
| 37 | V-belt 978777 | 978777 |
| Details | |
| Engine model | TAD1030G TAD1030GE, TAD1031GE, TAD1032GE TAD1030P TD100G-87 TD100G-87, TD1030ME, TWD1030ME TD100G-87, TD1030VE, TAD1030V, TWD1031VE, TAD1030VE TD1010G, TWD1010G TD1210G, TWD1210G, TWD1211G TD1210G, TWD1210G, TWD1211G, TAD1231GE, TAD1232GE TD121G-87, TWD1210V, TWD1211V, TWD1230VE, TWD1231VE TD121GP-87, TWD1210P, TWD1211P TWD1210P, TWD1211P TWD1230ME |
| Application | Belt Tensioner Device Belt Tensioner Device, Early Design Belt Tensioner Device, Early Design: A Belt Tensioner Device, Late Design: B Belt Tensioner Device, Late Design: TD121G -87 Belt Transmission and Belt Tensioner Device: A Thermostat Housing Water Pump and Thermostat Housing |
| Specification | |
| Descriptions | (966398) For sheet metal fan., L=2x1325mm L=2x1325mm L=2x1325mm (966398) |
