Alternator 1624089
| No. | Part Name | Part Number | Qty | Description |
| 1 | Alternator | 1578140 | 1 | 28V 45A |
| 1 | Alternator | 1624089 | 1 | 28V 45A |
| 1 | Alternator, exch | 3803320 | 1 | 28V 45A |
| 2 | Fan | 241363 | 1 | |
| 2 | Fan | 1613241 | 1 | |
| 3 | Pulley | 822573 | 1 | |
| 4 | V-belt | 966986 | 1 | L=2x1250mm |
| 5 | Bracket | 849354 | 1 | |
| 6 | Hexagon screw | 955555 | 1 | L=83mm |
| 7 | Lock nut | 950355 | 1 | |
| 8 | Hexagon screw | 970954 | 1 | L=60mm, (955324) |
| 9 | Flange screw | 946470 | 1 | |
| 9 | Flange screw | 965180 | 1 | |
| 10 | Tensioner | 847956 | 1 | |
| 11 | Tensioner | 849295 | 1 | |
| 12 | Flange screw | 947760 | 1 | M8x40mm |
| 13 | Tensioning loop | 466735 | 1 | |
| 14 | Washer | 191172 | 1 | Spec.867054, 867221. |
| 15 | Washer | 976944 | 2 | |
| 16 | Flange screw | 946173 | 1 | |
| 17 | Flange screw | 965183 | 1 | |
| 18 | Spring washer | 941905 | 1 | Replaced by 1306630, AQ125A USA MO-7545816/XXXX. AQ125A MO-7546500/XXXX. |
| 19 | Lock nut | 963104 | 1 | |
| 20 | 941881 | 1 | ||
| 2A | Washer | 945544 | 1 | |
| 2B | Spring pin | 1610144 | 1 | |
| 8A | Spring washer | 941908 | 1 |
| Item | Part Name | Part No. |
| 1 | Alternator 1624089 | 1624089 |
| Details | |
| Engine model | TD610M TD610M, TD630ME, TD730ME TWD630ME |
| Application | Alternator 28V 45A, Components Alternator, Low-Left Mounted Alternator, Low-Right Mounted: A Alternator, Low-Right Mounted: C |
| Specification | |
| Descriptions | 28V 45A |
