Volvo 22280217 Wiring harness 22280217 Electrical System spare parts-Generator engine parts Mall

Wiring harness 22280217

0 reviews Write a review

Qty

No.	Part Name	Part Number	Qty	Description
1	Wiring harness	22280217	1	Replaced by 22638131
1	Wiring harness	22638131	1	REplaced by 22875695
1	Wiring harness	22875695	1
2	Retainer	8131393	6	For cable to unit injectors.
3	Cable tie	983472	8	For cable to unit injectors.
4	Cable tie	980881	1
5	Retainer	3545508	1
6	Retainer	3121512	1
7	Cable tie	948211	1
8	Heat shield	22074217	1
9	Cable tie	22343166	2
10	Tube	20711293	2
11	Bracket	21927928	1
12	Flange screw	984737	1
13	Flange screw	984816	2
14	Pressure sensor, crankcase pressure	21634017	1
15	Temperature sensor, temperature	21531072	1
16	Pressure sensor, oil-pressure	21634021	1
16	Pressure sensor	22899626	1	SN2013690141-
17	Ring	3963413	1
18	Attaching clamp	1545432	2
19	Flange screw	984733	7
20	Sensor, charge pressure/tempera ture	3843012	1
21	Flange screw	984726	2
22	Bracket	22566969	1
23	Flange screw	984734	1
24	Clamp	942400	2
25	Speed monitor, flywheel	21426987	2
26	Flange screw	984725	2
27	Adapter	994291	1
28	Control unit	21918597	1
29	Six point socket scr	972411	2
30	Six point socket scr	969422	2
31	Six point socket scr	969598	3
32	Plug	1079677	3
33	Rubber cushion	1079687	3
34	Bracket	21866975	1	Replaced by 22860712
34	Bracket	22860712	1
35	Cover	21738845	1
36	Button	21827824	1
37	Retainer	873944	1
38	Six point socket scr	972411	2
39	Fuse	969161	1	10A
40	Fuse	969163	1	25A
42	Sealing plug	3840433	1
43	Six point socket scr	972399	8
44	Decal	21243308	1
46	Cable tie	993183	2

Item	Part Name	Part No.
1	Wiring harness 22280217	22280217
