Thermometer 873196
| No. | Part Name | Part Number | Qty | Description |
| 1 | Tachometer, hour/tachometer | 854908 | 1 | Replaced by operating clock/tachometer 873998 and intermediate ring 873721., 24V |
| 1 | Tachometer, tachometer | 872040 | 1 | Replaced by operating clock/tachometer 873998 and intermediate ring 873721., 24V |
| 2 | Tachometer kit, hour/tachometer | 873998 | 1 | Used without diod cable 873695., 12V-24V |
| 4 | Ring | 873517 | 1 | |
| 5 | Brace kit | 873208 | 1 | |
| 6 | Bulb | 943638 | 1 | For 873625,873624,873664 |
| 7 | Bulb socket | 863945 | 1 | For 873625,873624,873664 |
| 8 | Diode cable, tachometer | 873695 | 1 | |
| 8 | Cable kit | 874014 | 1 | For 874012 |
| 9 | Intermediate ring | 873721 | 1 | 80-72mm |
| 10 | Thermometer, temperature | 849848 | 1 | 24V |
| 10 | Oil pressure gauge, oil-pressure | 849849 | 1 | 24V |
| 10 | Voltmeter | 862096 | 1 | |
| 10 | Thermometer, oil | 863408 | 1 | |
| 10 | Hour recorder, hour meter | 872479 | 1 | 12-24V |
| 10 | Thermometer | 873196 | 1 | |
| 10 | Oil pressure gauge | 873198 | 1 | |
| 11 | Front ring | 858644 | 1 | For 872040., D=95mm |
| 12 | Front ring | 858643 | 1 | (828542) |
| 13 | Bulb socket | 808175 | 1 | |
| 13 | Bulb socket | 863945 | 1 | For 873625,873624,873664 |
| 14 | Bulb | 182059 | 1 | |
| 14 | Bulb | 828818 | 1 | 24V 2WBA7S |
| 14 | Bulb | 863947 | 1 | 24V 1, 2W, W2x4,6d |
| 15 | Horn | 874050 | 1 | 24V, (872874) |
| 16 | Sleeve | 819350 | 1 | |
| 17 | Lens | 827766 | 1 | |
| 18 | Switch | 875819 | 1 | |
| 19 | Nut | 843002 | 1 | |
| 20 | Knob | 837726 | 1 |
| Item | Part Name | Part No. |
| 10 | Thermometer 873196 | 873196 |
| Details | |
| Engine model | TAD1030GE, TAD1031GE, TAD1032GE, TAD1031G TAD1230G, TD1210G, TWD1210G, TWD1211G, TAD1231GE, TAD1232GE TAD1240GE, TAD1241GE, TAD1242GE TAD1640GE, TAD1641GE, TAD1642GE, TWD1663GE TAD1641VE, TAD1642VE, TAD1643VE TAD1650GE, TAD1651GE TAD940VE, TAD941VE, TAD942VE, TAD943VE, TAD950VE, TAD951VE, TAD952VE TD610G, TWD610G, TD710G, TWD710G, TAD730G, TWD740GE, TAD740GE, TAD741GE TWD1240VE, TAD1241VE, TAD1242VE, TAD1250VE, TAD1251VE, TAD1252VE TWD1644GE, TWD1645GE TWD1672GE, TWD1673GE |
| Application | Electrical Materials Electrical Materials, Instrument |
| Specification | |
| Descriptions | D=52mm With numerical dial plate., 24V |
