Attaching clamp 1545432
| No. | Part Name | Part Number | Qty | Description |
| 1 | Oil pump | 470343 | 1 | Repl by 478285 |
| 2 | Tab washer | 190529 | 2 | |
| 3 | Hexagon screw | 955538 | 4 | |
| 4 | Sealing ring | 470383 | 2 | SN-2120226439 |
| 5 | Hexagon screw | 955533 | 2 | For engine with 40° angle of inclination, L=102mm |
| 6 | Spring washer | 941907 | 2 | |
| 7 | Strainer | 470379 | 1 | SN-2120226439 |
| 8 | Bracket | 470385 | 1 | SN-2120226439 |
| 9 | Flange screw | 942402 | 2 | |
| 10 | Oil pressure pipe | 470375 | 1 | |
| 11 | Fitting | 466908 | 1 | |
| 12 | Spacer | 470376 | 1 | SN-2120226439 |
| 13 | Sealing ring | 470263 | 1 | Late type |
| 14 | Hexagon screw | 959794 | 2 | |
| 15 | Spring washer | 941907 | 2 | |
| 16 | Fitting | 470377 | 1 | SN-2120226439 |
| 17 | Ferrule | 956973 | 1 | |
| 18 | Bracket | 470918 | 1 | |
| 19 | Flange screw | 942402 | 2 | |
| 20 | Attaching clamp | 1545432 | 1 | |
| 21 | Flange screw | 942402 | 1 | |
| 22 | Washer | 955894 | 1 | |
| 23 | Lock nut | 945467 | 1 | Late type |
| 24 | Extension pipe | 412845 | 1 | |
| 25 | Oil dipstick | 944663 | 1 | |
| 26 | Oil sump | 470160 | 1 | |
| 27 | Magnetic plug | 949175 | 1 | |
| 28 | Gasket | 18813 | 1 | |
| 29 | Gasket | 424603 | 1 | |
| 30 | Flange screw | 942402 | 41 | |
| 31 | Bracket | 468653 | 1 | |
| 32 | Hexagon screw | 955525 | 2 | |
| 33 | Spring washer | 941907 | 2 | |
| 34 | Washer | 960141 | 2 | |
| 36 | Oil filter housing | 470979 | 1 | Compl repl by 470983 |
| 37 | Nipple | 466623 | 2 | |
| 38 | Oil filter | 466634 | 2 | |
| 39 | O-ring | 949659 | 1 | |
| 40 | Gasket | 469486 | 1 | |
| 41 | Hexagon screw | 955525 | 2 | |
| 42 | Hexagon screw | 942529 | 2 | |
| 43 | Hexagon screw | 940115 | 2 | |
| 44 | Spring washer | 941907 | 2 | |
| 45 | Sealing ring | 469846 | 1 | |
| 46 | Valve seat | 469468 | 1 | |
| 47 | Valve cone | 471085 | 1 | |
| 48 | Compression spring | 470291 | 1 | |
| 49 | Spring | 468727 | 1 | For 424920 |
| 50 | O-ring | 949658 | 1 | (925061) early type |
| 51 | Cover | 469465 | 1 | |
| 52 | Spring washer | 949607 | 2 | |
| 53 | Hexagon screw | 955512 | 2 | |
| 54 | Oil bilge pipe | 844870 | 1 | |
| 55 | Hollow screw | 26013 | 1 | AQ115A MOXXXX/86909-. |
| 56 | Gasket | 957181 | 2 | |
| 57 | Clamp | 941950 | 1 | |
| 58 | Hexagon screw | 940161 | 1 | For engine with 40° angle of inclination, L=45mm |
| 59 | Spacer sleeve | 807182 | 1 | |
| 60 | Cap | 842235 | 1 | |
| 61 | Hose clamp | 943471 | 1 | (951787) |
| 62 | Hexagon screw | 940100 | 2 | |
| 63 | Spring washer | 949607 | 2 | |
| 64 | Cover | 471752 | 1 | |
| 65 | O-ring | 949658 | 1 | (925061) early type |
| 66 | Reduction valve | 471707 | 1 | |
| 67 | Sealing ring | 469846 | 1 | |
| 44A | Spring washer | 942336 | 4 |
| Item | Part Name | Part No. |
| 20 | Attaching clamp 1545432 | 1545432 |
| Details | |
| Engine model | TAD1030G TAD1030GE, TAD1031GE, TAD1032GE TAD1030V TAD1230G, TD1210G, TWD1210G, TWD1211G TAD1230P, TD121GP-87, TWD1210P, TWD1211P TAD1230P, TD121GP-87, TWD1210P, TWD1211P, TD1210G, TWD1210G, TWD1211G TAD1231GE, TAD1232GE TAD1340VE, TAD1341VE, TAD1342VE, TAD1343VE, TAD1344VE, TAD1345VE TAD1340VE, TAD1341VE, TAD1342VE, TAD1343VE, TAD1344VE, TAD1345VE, TAD1360VE, TAD1361VE, TAD1362VE, TAD1363VE, TAD1364VE, TAD1365VE TAD1341GE, TAD1342GE, TAD1343GE, TAD1344GE, TAD1345GE, TAD1350GE, TAD1351GE, TAD1352GE, TAD1353GE TAD1341GE, TAD1342GE, TAD1343GE, TAD1344GE, TAD1345GE, TAD1350GE, TAD1351GE, TAD1352GE, TAD1353GE, TAD1354GE, TAD1355GE TAD1350VE TAD1351VE, TAD1352VE, TAD1353VE TAD1352VE TAD1360VE TAD1360VE, TAD1361VE, TAD1362VE, TAD1363VE, TAD1364VE, TAD1365VE TAD1361VE TAD1363VE TAD1371VE, TAD1372VE, TAD1373VE, TAD1374VE, TAD1375VE TAD1640GE, TAD1641GE, TAD1642GE, TAD1650GE, TAD1651GE, TWD1643GE, TWD1652GE, TWD1653GE, TWD1663GE TAD1640GE, TAD1641GE, TAD1642GE, TWD1643GE TAD1641VE, TAD1642VE, TAD1643VE TAD1641VE, TAD1642VE, TAD1643VE, TAD1650VE, TAD1660VE, TAD1661VE, TAD1662VE, TAD1640VE-B, TAD1641VE-B, TAD1642VE-B, TAD1662VE EU5 TAD1643VE-B TAD1650VE TAD1650VE-B, TAD1651VE TAD1670VE, TAD1671VE, TAD1672VE TD1030ME TD1030VE, TWD1031VE TD120HP-86, TD121G, TD121GG, TD121GG-86, TD121GGP, TID121K, TID121KG, TID121KP, TID121KGP, TID121LG, TID121LGP, TID121LP TD121G-87, TD121GG-87, TD121GGP-87, TD121GPB-87 TD121G-87, TID121K-87 TD121G-87, TWD1230VE, TWD1231VE TD640VE TID121FG TWD1030ME TWD1031VE TWD1210V, TWD1211V, TAD1230V TWD1230ME TWD1643GE, TWD1652GE, TWD1653GE, TWD1663GE TWD1644GE, TWD1645GE TWD1652GE, TWD1653GE TWD1672GE, TWD1673GE |
| Application | Control Unit and Connector Electric System Brackets and Connectors Electric system, engine wiring harness Electrical System Electrical System 2013618595- Electrical System SN-2013618594 Electrical System SN2013618595- Engine Heater 110V/1500W: A Engine Heater separately Mounted, 240V-2000W Engine Heater, Separately Mounted Engine Heater, Separately Mounted SN-2016198146 Fuel System SN2016008441- SN2016045622 Lubricating System Lubricating System, 40° Inclination Lubricating System, Earlier Production Lubricating System, Later Production Lubricating System, Later Production: A Lubricating System, Later Production: B Lubricating System, Tilted Oil Sump Lubricating System: A Lubricating System: B LUBRICATING SYSTEM: TID121FP Lubrication System, 40° Inclination, Earlier Production Oil Cooler Oil Filter Housing and Oil Filter Oil Filter Housing, Components. Alternative Mounting. Starter Element Turbocharger |
| Specification | |
| Descriptions | (949786) For low-mounted turbo. For low-mounted turbo., SNXXXXXXXXXX/278329- |
