Oil pan 20702520

Oil pan 20702520

Oil pan 20702520

0 reviews Write a review
  • Brandsvolvo penta
  • Part No.: 20702520
  • Availability: 联系我们
No. Part Name Part Number Qty Description
1 Oil pan 20702520 1
2 Magnetic plug 20571854 1
3 Sealing ring 20579690 1
4 Connection pipe 20462497 1
5 Sealing ring 20555696 1 (421629)
6 Flange screw 946440 2
7 Bracket 3807087 1
8 Flange lock nut 977938 2
9 Hose 3831383 1
10 Hose clamp 994561 2
11 Flange screw 945444 2
12 Oil filler pipe 20808091 1
13 Oil filler cap 20807510 1
14 Rubber washer 20365079 1
15 Dipstick 21839748 1
16 O-ring 949187 2
17 Pipe 20724256 1
18 O-ring 949656 1
19 Pipe 3807085 1
20 Six point socket scr 975371 1
21 Retainer 20586869 1
22 Flange screw 966378 4
23 O-ring 20586720 1
24 Sensor 24424110 1 Replaced by sender 21042447.
25 O-ring 944126 1
26 Flange screw 946934 2
27 Flange screw 948356 3
28 Retainer 20700754 3
29 Sealing strip 20532272 1
30 Flange screw 20463185 16 Replaced by 20739547
31 Oil pump 8170261 1
32 Suction pipe 8170878 1
33 Sealing ring 465784 1
34 Flange screw 965180 3
35 Flange screw 968842 1 L=110mm
36 Flange screw 471734 4
37 Pressure pipe 20411298 1
40 Sealing ring 8170558 1
41 Piston cooling jet 3155151 6
42 Flange screw 966378 6
43 Nozzle, transmission 8170583 1
44 Screw 471586 1
45 Control valve 21452473 1 Replaced by 21596642
46 Sealing ring 20526428 1
47 Outlet pipe 20734464 1
48 Flange screw 3165142 2
49 Sealing ring 1677370 2
50 Flange screw 966378 1
Item Part Name Part No.
1 Oil pan 20702520 20702520
volvo penta Oil pan 20702520 Drawing
Details
Engine model TAD1250VE, TAD1251VE, TAD1252VE
Application Lubricating System
