Piston ring 21304975
| No. | Part Name | Part Number | Qty | Description |
| 1 | Crankshaft | 20900811 | 1 | SN01098273- |
| 2 | Main bearing | 20405529 | 5 | U.S=0,25mm, SN-10594934 |
| 2 | Main bearing | 20405541 | 5 | U.S=0.50mm |
| 2 | Main bearing | 21141948 | 5 | Std |
| 2 | Main bearing | 21234191 | 5 | U.S=0,25mm, SN10594935- |
| 3 | Safety washer | 11700315 | 2 | O.S=0.20mm (3.1mm) |
| 3 | Thrust washer kit | 20405899 | 2 | Std |
| 4 | Lip seal | 20412286 | 1 | |
| 8 | Cylinder liner kit | 3843536 | 4 | |
| 10 | O-ring | 20412762 | 8 | |
| 12 | Gudgeon pin | 20405577 | 4 | |
| 13 | Snap ring | 20405576 | 8 | |
| 14 | Piston ring | 21304975 | 4 | |
| 15 | Connecting rod | 20585982 | 4 | |
| 16 | Flange screw | 11700326 | 8 | |
| 17 | Grooved pin | 20459134 | 4 | |
| 18 | Bushing | 11700325 | 4 | |
| 19 | Bearing | 20766790 | 4 | Std, Only for 20585982 |
| 19 | Big-end bearing kit | 20790423 | 4 | U.S=0.25mm, Only for 20585982 |
| 19 | Big-end bearing kit | 20790428 | 4 | U.S=0.50mm, Only for 20585982 |
| 20 | Spring pin | 20405634 | 1 | 18X24 |
| 21 | V-belt pulley | 20405725 | 1 | For fan mounted on coolant pump., Alternator dw/width 238,2/10., Pump dw/width 237,8/13. |
| 22 | Six point screw | 20405724 | 4 | |
| 23 | Vibration damper | 20546792 | 1 | (248x32) |
| 24 | Flange screw | 888289 | 9 |
| Item | Part Name | Part No. |
| 14 | Piston ring 21304975 | 21304975 |
| Details | |
| Engine model | TAD520GE TAD520VE TAD530GE, TAD531GE TAD532GE TAD720GE TAD720VE TAD721GE, TAD722GE TAD721VE TAD730GE, TAD731GE TAD732GE, TAD733GE TD520GE TD520VE TD720GE |
| Application | Crank Mechanism Crank Mechanism SN-779906 Stage 2, Tier 2 Crank Mechanism SN1058414- Stage 2, Tier 2 Crank Mechanism SN779907- Stage 2, Tier 2 Crank Mechanism Stage 1, Tier 1 Crank Mechanism Stage 2, Tier 2 Repair Kits Repair Kits: A Repair Kits: B |
