Wiring harness 873989
| No. |
Part Name |
Part Number |
Qty |
Description |
| 1 |
Control unit |
3828557 |
1 |
|
| 3 |
Box |
3828542 |
1 |
|
| 4 |
Cap |
3828543 |
1 |
|
| 5 |
Electronic unit |
11042141 |
1 |
|
| 6 |
Cross recessed screw |
956076 |
2 |
|
| 7 |
Bracket |
3827397 |
1 |
|
| 8 |
Flange screw |
946934 |
2 |
|
| 9 |
Clamp |
952634 |
2 |
|
| 10 |
Relay |
3171420 |
3 |
|
| 11 |
Wiring harness |
873989 |
1 |
|
| 12 |
Wiring harness |
873820 |
1 |
|
| 13 |
Flange lock nut |
949278 |
2 |
|
| 14 |
Lock nut |
946035 |
3 |
|
| 15 |
Spacer washer |
949873 |
3 |
|
| 16 |
Bracket |
3828393 |
1 |
|
| 17 |
Attaching bar |
3828458 |
1 |
|
| 18 |
Rubber cushion |
3828479 |
2 |
|
| 19 |
Vibration damper |
3574797 |
1 |
|
| 20 |
Flange screw |
945444 |
3 |
|
| 21 |
Flange nut |
945407 |
5 |
For THD102KB and THD102KD. |
| 22 |
Bracket |
965577 |
1 |
|
| 23 |
Clamp |
952634 |
4 |
|
| 24 |
Clamp |
952633 |
1 |
D = 22.2 MM LATE TYPE |
| 25 |
Clamp |
952625 |
1 |
|
| 26 |
Flange screw |
946544 |
5 |
For THD102KB and THD102KD. |
| 27 |
Flange nut |
945407 |
5 |
For THD102KB and THD102KD. |
| 28 |
Bracket |
965571 |
3 |
|
| 29 |
Clamp |
952623 |
2 |
|
| Item |
Part Name |
Part No. |
| 11 |
Wiring harness 873989 |
873989 |
| Details |
| Engine model |
DH10A |
| Application |
Control Unit and Cables, Gearbox |
Tags:
Wiring harness,
Volvo Penta,
873989
