Clutch 342561
| No. |
Part Name |
Part Number |
Qty |
Description |
| 1 |
Clutch |
342561 |
1 |
15'' - Borg & Beck 49914-38-PTIR |
| 2 |
Cover |
331752 |
1 |
|
| 3 |
Bushing |
331604 |
4 |
|
| 4 |
Screw |
955657 |
4 |
|
| 5 |
Pressure plate |
331753 |
1 |
|
| 6 |
Spring |
345437 |
12 |
|
| 7 |
Spring |
332536 |
12 |
|
| 8 |
Seat |
331614 |
12 |
|
| 10 |
Lever |
331606 |
4 |
|
| 11 |
Spring |
331607 |
4 |
|
| 12 |
Edge |
331608 |
4 |
|
| 15 |
Pin |
331611 |
4 |
|
| 16 |
Thrust washer |
331754 |
1 |
|
| 17 |
Spring |
331613 |
4 |
|
| 21 |
Locating pin |
191990 |
2 |
|
| 22 |
Hexagon screw |
940116 |
12 |
AQ170B MOXXXX/87713-., L=25mm |
| 23 |
Spring washer |
941909 |
12 |
AQ170B MOXXXX/87713-., BB170B MOXXXX/89353-. |
| 24 |
Lever |
954693 |
1 |
Engine with gear box 254603 |
| 24 |
Lever |
954707 |
1 |
|
| 25 |
Hexagon screw |
941795 |
1 |
|
| 26 |
Shaft |
346796 |
1 |
|
| 27 |
Ball bearing |
181409 |
2 |
|
| 28 |
Sealing ring |
191875 |
4 |
|
| 29 |
Retaining ring |
914526 |
2 |
|
| 30 |
Release fork |
346806 |
1 |
D42A PP spec.16053 |
| 32 |
Hexagon screw |
955562 |
2 |
L=38mm |
| 33 |
Washer |
31337 |
1 |
|
| 35 |
Release bearing |
329309 |
1 |
|
| 35 |
Bearing |
355062 |
1 |
Engine with gear box 254603 |
| 36 |
Lubricating hose |
353059 |
1 |
|
| 37 |
Spring washer |
941912 |
1 |
|
| 38 |
Hexagon nut |
955793 |
1 |
|
| 39 |
Lubricator |
914134 |
2 |
|
| Item |
Part Name |
Part No. |
| 1 |
Clutch 342561 |
342561 |
| Details |
| Engine model |
D70B |
| Application |
Friction Clutch and Installation Components |
| Specification |
| Descriptions |
15'' - Borg & Beck 49914-38-PTIR |
Tags:
Clutch,
Volvo Penta,
342561
