Lever 3035878
| No. |
Part Name |
Part Number |
Qty |
Description |
| 1 |
Pressure cylinder |
1080390 |
1 |
|
| 2 |
Bracket |
424942 |
1 |
|
| 3 |
Washer |
941744 |
2 |
|
| 4 |
Flange screw |
967949 |
2 |
|
| 5 |
Lever |
3035878 |
1 |
|
| 6 |
O-ring |
1587176 |
1 |
|
| 7 |
Hexagon nut |
945893 |
1 |
|
| 8 |
Elbow nipple |
945916 |
1 |
|
| 9 |
Leak-off line |
479690 |
1 |
|
| 10 |
Nipple |
968695 |
1 |
|
| 11 |
Nipple |
976444 |
1 |
|
| 12 |
Solenoid valve |
3986621 |
1 |
|
| 14 |
Flange screw |
946440 |
2 |
|
| 15 |
Bracket |
965555 |
1 |
1x9x60 |
| 16 |
Clamp |
952625 |
2 |
|
| 17 |
Flange screw |
946934 |
1 |
|
| 18 |
Flange lock nut |
949278 |
1 |
|
| 5A |
Hexagon screw |
955637 |
1 |
|
| 5B |
Spring washer |
941906 |
1 |
|
| Item |
Part Name |
Part No. |
| 5 |
Lever 3035878 |
3035878 |
| Details |
| Engine model |
THD102KD, THD102KB |
| Application |
Pneumatical Stop Control |
