Electronic unit 828783
| No. | Part Name | Part Number | Qty | Description |
| 1 | Instrument panel | 848071 | 1 | |
| 2 | Instrument panel | 828588 | 1 | |
| 3 | Tachometer | 828600 | 1 | |
| 4 | Attaching ring | 828558 | 1 | |
| 5 | Front ring | 828559 | 1 | |
| 6 | Thermometer | 828613 | 1 | |
| 7 | Front ring | 828542 | 3 | |
| 8 | Oil pressure gauge | 828619 | 1 | |
| 9 | Hour counter | 828615 | 1 | |
| 10 | Bulb socket | 808175 | 4 | |
| 11 | Bulb | 19923 | 4 | |
| 11 | Bulb | 182059 | 4 | |
| 12 | Starter switch | 828778 | 1 | Repl by 864277 |
| 13 | Key | 828676 | 2 | State key code when oredering |
| 14 | Round nut | 1581184 | 1 | |
| 15 | Buzzer | 828587 | 1 | |
| 16 | Toggle switch | 828584 | 1 | |
| 16 | Toggle switch | 828585 | 1 | |
| 17 | Nut | 828586 | 2 | |
| 18 | Sign | 828560 | 1 | |
| 19 | Bulb | 828818 | 4 | 24V 2WBA7S |
| 20 | Reflector | 828784 | 1 | |
| 21 | Electronic unit | 828783 | 1 | |
| 22 | Cross recessed screw | 941615 | 2 | |
| 23 | Spring washer | 941904 | 2 | |
| 24 | Cross recessed screw | 949947 | 1 | Alt |
| 25 | Spring washer | 941904 | 1 | |
| 26 | Guide ring | 828803 | 3 |
| Item | Part Name | Part No. |
| 21 | Electronic unit 828783 | 828783 |
| Details | |
| Engine model | TD60D-83 TD70G-83 TID121FG TID60D TID60DG TID70G |
| Application | Instrument Panel INSTRUMENT PANEL AND INSTALLATION COMPONENTS: A INSTRUMENT PANEL AND INSTALLATION COMPONENTS: B INSTRUMENT PANEL AND INSTALLATION COMPONENTS: C |
Tags: Electronic unit, Volvo Penta, 828783
