Tachometer kit 874012
| No. | Part Name | Part Number | Qty | Description |
| 1 | Tachometer, hour/tachometer | 854908 | 1 | Replaced by operating clock/tachometer 873998 and intermediate ring 873721., 24V |
| 1 | Tachometer, tachometer | 872040 | 1 | Replaced by operating clock/tachometer 873998 and intermediate ring 873721., 24V |
| 1 | Tachometer kit | 877179 | 1 | 24V, TWD1231GE |
| 2 | Tachometer kit | 873722 | 1 | |
| 2 | Tachometer kit | 874012 | 1 | |
| 4 | Ring | 873683 | 1 | |
| 5 | Brace kit | 873208 | 1 | |
| 6 | Bulb | 943638 | 1 | For 873625,873624,873664 |
| 7 | Bulb socket | 863945 | 1 | For 873625,873624,873664 |
| 8 | Diode cable, tachometer | 873695 | 1 | |
| 8 | Cable kit | 874014 | 1 | For 874012 |
| 9 | Intermediate ring | 873721 | 1 | 80-72mm |
| 10 | Thermometer, temperature | 849848 | 1 | 24V |
| 10 | Oil pressure gauge, oil-pressure | 849849 | 1 | 24V |
| 10 | Voltmeter | 862096 | 1 | |
| 10 | Thermometer, oil | 863408 | 1 | |
| 10 | Hour recorder, hour meter | 872479 | 1 | 12-24V |
| 10 | Thermometer | 873196 | 1 | |
| 10 | Oil pressure gauge | 873198 | 1 | |
| 11 | Front ring | 858644 | 1 | For 872040., D=95mm |
| 12 | Front ring | 858643 | 1 | (828542) |
| 13 | Bulb socket | 808175 | 1 | |
| 13 | Bulb socket | 863945 | 1 | For 873625,873624,873664 |
| 14 | Bulb | 182059 | 1 | |
| 14 | Bulb | 828818 | 1 | 24V 2WBA7S |
| 14 | Bulb | 863947 | 1 | 24V 1, 2W, W2x4,6d |
| 15 | Horn | 8143028 | 1 | 24V, (872874) |
| 16 | Sleeve | 819350 | 1 | |
| 17 | Lens | 827766 | 1 | |
| 18 | Switch | 875819 | 1 | |
| 19 | Nut | 843002 | 1 | |
| 20 | Knob | 837726 | 1 |
| Item | Part Name | Part No. |
| 2 | Tachometer kit 874012 | 874012 |
| Details | |
| Engine model | TAD1230G, TD1210G, TWD1210G, TWD1211G, TAD1231GE, TAD1232GE TAD1230P, TD121GP-87, TWD1210P, TWD1211P TAD520VE, TAD720VE, TAD721VE, TAD722VE TD420VE, TAD420VE, TAD620VE |
| Application | Electrical Materials Electrical Materials, Instrument |
