V-belt 976487
| No. | Part Name | Part Number | Qty | Description |
| 1 | Alternator | 872018 | 1 | For 12V electric system., 14V 50A repl by 872926 |
| 1 | Alternator | 872021 | 1 | For 24V electric system., 28V 60A, repl by 873757 |
| 1 | Alternator | 872926 | 1 | For 12V electric system., 14V 50A E.U=3803227 |
| 1 | Alternator | 873757 | 1 | 28V 60A, repl by 873771 |
| 2 | Fan | 847707 | 1 | Included in alternator |
| 2 | Fan kit | 860281 | 1 | |
| 3 | Pulley | 822573 | 1 | |
| 4 | V-belt | 976487 | 1 | L=2x1150mm |
| 5 | Bracket | 847926 | 1 | |
| 6 | Screw | 847925 | 1 | |
| 7 | Lock nut | 971089 | 1 | Included in spring kit 876019. |
| 8 | Flange screw | 947760 | 2 | M8x40mm |
| 9 | Tensioner | 847956 | 1 | |
| 10 | Tensioner | 847957 | 1 | |
| 11 | Flange screw | 946173 | 1 | |
| 12 | Tensioning loop | 466734 | 1 | |
| 13 | Flange screw | 947760 | 1 | M8x40mm |
| 14 | Washer | 191172 | 1 | Spec.867054, 867221. |
| 15 | Flange screw | 946173 | 1 | |
| 6A | Spring pin | 1610144 | 1 |
| Item | Part Name | Part No. |
| 4 | V-belt 976487 | 976487 |
| Details | |
| Engine model | TD610M, TD630ME, TD730ME TD610M, TD630ME, TWD630ME TD610M, TD630ME, TWD630ME, TD730ME, TWD730ME, TWD731ME TD610V, TD630VE TD610V, TD630VE, TWD630VE TD610V, TWD610V, TD630VE, TWD630VE TD71A, TID71A, TD730VE, TWD731VE TD71A, TID71A, TWD710V, TD730VE TD71A, TID71A, TWD710V, TWD731VE, TAD730V TD71A, TID71A, TWD731VE TD730VE TWD610P TWD610P, TWD710P, TAD730P TWD710P |
| Application | Alternator, Low-Left Mounted Alternator, Low-Left Mounted SN-2061150163 Alternator, Low-Left Mounted SN-2071115245 Alternator, Low-Left Mounted SN2061150164- Alternator, Low-Left Mounted SN2071115246- |
| Specification | |
| Descriptions | L=2x1150mm L=2x1150mm (966869) |
