Gasket 424619
| No. | Part Name | Part Number | Qty | Description |
| 1 | Air filter | 842280 | 1 | |
| 2 | Hose clamp | 943484 | 1 | (951801) |
| 3 | Fitting | 843409 | 1 | |
| 4 | Hose clamp | 943483 | 1 | (951800) |
| 5 | Connecting pipe | 845637 | 1 | |
| 6 | Gasket | 424619 | 1 | |
| 7 | Hexagon screw | 955532 | 2 | Only for thermoswitch control 837500,837501., L=95mm |
| 7 | Hexagon screw | 959793 | 2 | |
| 8 | Spring washer | 941907 | 4 | |
| 9 | Bracket | 845648 | 1 | |
| 10 | Hexagon screw | 955532 | 3 | Only for thermoswitch control 837500,837501., L=95mm |
| 11 | Spring washer | 941907 | 3 | |
| 12 | Spacer sleeve | 821541 | 1 | L=37mm, spec 9757 |
| 12 | Spacer sleeve | 821542 | 2 | L=51mm |
| 13 | Tensioning band | 821028 | 1 | |
| 14 | Pin | 31405 | 1 | |
| 15 | Clevis pin, threaded | 31404 | 1 | |
| 16 | Hexagon screw | 31406 | 1 | |
| 17 | Hexagon screw | 940135 | 3 | |
| 18 | Spring washer | 941907 | 3 | |
| 19 | Cross recessed screw | 956091 | 1 | |
| 20 | Spring washer | 941906 | 1 | |
| 21 | Connecting pipe | 843717 | 1 | ÅKERMAN |
| 22 | Gasket | 862590 | 1 | (843718) |
| 24 | Clamping ring | 843703 | 1 | ÅKERMAN. |
| 25 | Attaching ring | 843704 | 1 | ÅKERMAN. |
| 26 | Gasket | 862590 | 1 | (843718) |
| 27 | Hex. socket screw | 959223 | 1 | L = 30 MM |
| 27 | Hex. socket screw | 959224 | 1 | When emergency stop is mounted., L=35mm |
| 27 | Hex. socket screw | 959233 | 1 | When emergency stop is mounted., L=80mm |
| 28 | Spring washer | 941907 | 3 |
| Item | Part Name | Part No. |
| 6 | Gasket 424619 | 424619 |
| Details | |
| Engine model | D70CHC D70CHC, D70CRC D70CRC TAD121CHC TAD730G TAD730P TAD730V TAD740GE TAD740GE, TAD741GE TAD741GE TD100CHC TD100CRC TD121CHC TD121CRC TD31ACE TD45B TD610G TD610M TD610V TD610V, TD630VE TD61A TD61ACE TD61AG TD61AP TD61AW TD630ME TD630VE TD640VE TD70CHC TD70CRC TD710G TD71A TD71ACE TD71AG TD71AP TD71AW TD730ME TD730VE TWD610G TWD610P TWD610V TWD710P TWD710V TWD740GE TWD740VE |
| Application | Air Filter and Installation Components Induction and Exhaust Manifold with Installation Components Induction and Exhaust Manifold: A Induction and Exhaust Manifold: B Induction and Exhaust System: A Induction and Exhaust System: B Induction Manifold with Installation Components Induction Manifold with Installation Components: A Induction Manifold with Installation Components: B Induction Manifold with Installation Components: TD61AGP Induction Manifold with Installation Components: TD71AGP Induction Manifold with Installation Components: TD71APB Induction Manifold, Low Mounted Turbocharger Induction Manifold, Low Mounted Turbocharger: A Induction Manifold, Low Mounted Turbocharger: B Inlet and Exhaust Manifold Inlet Manifold Inlet-,Exhaust Manifold and Turbocharger Repair Kit Repair Kit: A Repair Kit: B Repair Kits Repair Kits: A Repair Kits: B Repair Kits: C Repair Kits: D |
| Specification | |
| Descriptions | (466271) (466436) Included in gasket kit. |
