Gasket 479107
| No. | Part Name | Part Number | Qty | Description |
| 0 | Gasket | 11994 | 2 | |
| 0 | Gasket | 11998 | 2 | |
| 0 | Gasket | 15304 | 1 | |
| 0 | Gasket | 18666 | 2 | |
| 0 | Gasket, plug | 18677 | 1 | |
| 0 | Gasket | 18818 | 2 | |
| 0 | Deflector | 70913 | 1 | |
| 0 | Ball bearing | 181538 | 1 | |
| 0 | Big-end bearing kit | 270124 | 6 | Std D |
| 0 | Big-end bearing kit | 270125 | 6 | 0,25mm u.s |
| 0 | Big-end bearing kit | 270126 | 6 | 0,50mm u.s |
| 0 | Big-end bearing kit | 270127 | 6 | U.S=0,75mm |
| 0 | Big-end bearing kit | 270128 | 6 | U.S=1,00mm |
| 0 | Big-end bearing kit | 270129 | 6 | U.S=1,25mm |
| 0 | Main bearing kit | 270438 | 7 | |
| 0 | Main bearing kit | 270439 | 7 | 0.25mm u.s |
| 0 | Main bearing kit | 270440 | 7 | 0.50mm u.s |
| 0 | Main bearing kit | 270441 | 7 | 0.75mm u.s |
| 0 | Main bearing kit | 270442 | 7 | 1.00mm u.s |
| 0 | Main bearing kit | 270443 | 7 | 1.25mm u.s |
| 0 | Cylinder head gasket | 270789 | 6 | |
| 0 | Sealing ring kit | 271157 | 6 | |
| 0 | Repair kit | 272813 | 1 | See group 10A |
| 0 | Piston ring kit | 275084 | 6 | |
| 0 | Cylinder liner kit | 275627 | 6 | |
| 0 | Sealing ring kit, gasket kit exhaust manifold | 275748 | 1 | |
| 0 | Overhaul kit | 275948 | 1 | See group 99 |
| 0 | De-carbonizing kit, decarbonizing | 276035 | 1 | |
| 0 | Overhaul kit | 276052 | 1 | See group 99 |
| 0 | Overhaul kit | 276155 | 1 | |
| 0 | Thrust washer kit | 276758 | 6 | Std D |
| 0 | Thrust washer kit | 276759 | 6 | 0,10mm o.s |
| 0 | Thrust washer kit | 276760 | 6 | 0,20mm o.s |
| 0 | Thrust washer kit | 276761 | 6 | 0,30mm o.s |
| 0 | Valve seat | 324343 | 2 | |
| 0 | Inlet valve | 324344 | 2 | |
| 0 | Spring | 324346 | 2 | |
| 0 | Spring | 324349 | 2 | |
| 0 | Spring | 324355 | 1 | |
| 0 | Guide | 326839 | 1 | |
| 0 | Gasket | 328731 | 1 | |
| 0 | Guide | 328756 | 2 | |
| 0 | Valve disc | 328757 | 2 | |
| 0 | Push rod | 331877 | 2 | |
| 0 | Guide | 331878 | 2 | |
| 0 | Bearing | 344231 | 1 | |
| 0 | Gasket | 346938 | 1 | |
| 0 | Retaining ring | 417466 | 12 | |
| 0 | Plane gasket | 420641 | 1 | |
| 0 | Plane gasket | 420643 | 1 | |
| 0 | Sealing ring | 421158 | 1 | |
| 0 | Wear ring | 421306 | 1 | |
| 0 | Gasket | 422130 | 1 | |
| 0 | Impeller | 422149 | 1 | |
| 0 | Spacer sleeve | 422202 | 1 | |
| 0 | Gudgeon pin | 422344 | 6 | Std |
| 0 | Sealing ring | 422413 | 6 | D=11mm |
| 0 | Sealing ring | 422414 | 6 | D=32mm |
| 0 | Sealing ring | 422415 | 6 | D=18mm |
| 0 | Gasket | 422626 | 1 | |
| 0 | Gasket | 422779 | 1 | |
| 0 | Sealing ring | 423123 | 1 | |
| 0 | Gasket | 423127 | 1 | |
| 0 | Gasket | 423138 | 1 | |
| 0 | Washer | 424133 | 1 | |
| 0 | O-ring | 424345 | 1 | |
| 0 | Sealing ring | 424580 | 1 | (941580) |
| 0 | Gasket | 424618 | 2 | |
| 0 | Gasket | 424693 | 6 | |
| 0 | Gasket | 424694 | 6 | |
| 0 | Gasket | 468557 | 1 | |
| 0 | Sealing ring | 469455 | 6 | |
| 0 | Sealing ring | 469477 | 1 | Replaced by 842427, 842428, 842429, 842423, 411710., Late type (424345) |
| 0 | Sealing ring | 469483 | 1 | (422581) |
| 0 | Gasket | 469487 | 1 | |
| 0 | O-ring | 469508 | 1 | Included in gasket kit. |
| 0 | O-ring | 469509 | 1 | Included in gasket kit. |
| 0 | Gasket | 469823 | 3 | |
| 0 | Sealing ring | 469829 | 6 | Included in gasket kit. |
| 0 | Sealing ring | 471219 | 1 | |
| 0 | Sealing ring | 471856 | 6 | |
| 0 | Valve cap | 478074 | 12 | |
| 0 | Gasket | 479107 | 6 | |
| 0 | Seal | 479260 | 6 | Included in gasket kit,decarbonizing 276035. |
| 0 | Gasket | 479264 | 1 | |
| 0 | Hub | 843597 | 1 | |
| 0 | Shaft | 844369 | 1 | |
| 0 | Gasket | 862603 | 1 | |
| 0 | Repair kit | 875661 | 1 | For 827021., See group 10A |
| 0 | Overhaul gasket kit, reconditioning | 876315 | 1 | |
| 0 | Gasket kit | 876354 | 1 | |
| 0 | Gasket kit | 876722 | 1 | See group 99 |
| 0 | Intake gasket kit, induction manifold | 876781 | 1 | |
| 0 | Gasket | 907132 | 3 | |
| 0 | Retaining ring | 914462 | 1 | |
| 0 | O-ring | 925059 | 1 | AQ115A compression 8,4:1. |
| 0 | O-ring | 925074 | 1 | |
| 0 | O-ring | 925255 | 1 | |
| 0 | Gasket | 940096 | 1 | |
| 0 | Spring washer | 941907 | 24 | |
| 0 | Gasket | 942703 | 1 | |
| 0 | Gasket | 947281 | 2 | |
| 0 | Gasket | 947620 | 2 | (233321) |
| 0 | O-ring | 949656 | 1 | |
| 0 | O-ring | 949658 | 1 | (925061) early type |
| 0 | Hexagon screw | 955525 | 2 | |
| 0 | Gasket | 969011 | 20 | |
| 0 | O-ring | 975610 | 1 | For engines without air compressor. |
| 0 | Sealing ring | 1542781 | 1 | |
| 0 | O-ring | 1542783 | 2 | |
| 0 | Roller bearing | 1542870 | 1 | (184437) |
| 0 | Spacer sleeve | 1542871 | 1 | (844281) |
| 0 | Sealing ring | 1544410 | 1 | |
| 0 | Sealing ring | 1544710 | 1 | |
| 0 | Sealing ring | 1545109 | 2 | |
| 0 | Gasket | 1545244 | 1 | |
| 0 | Sealing ring | 1545271 | 1 | Late type |
| 0 | Tab washer | 1545277 | 2 | Included in gasket kit. |
| 0 | Sealing ring | 1545283 | 1 | (1542833) |
| 0 | Ball bearing | 1660609 | 1 | (181670) |
| 0 | Sealing ring | 1676432 | 1 | Included in repair kit 3830711. |
| 0 | Gasket | 1697531 | 1 | |
| 0 | Impeller | 1698603 | 1 | |
| 0 | Repair kit, air compr. | 3090471 | 1 |
| Item | Part Name | Part No. |
| 0 | Gasket 479107 | 479107 |
| Details | |
| Engine model | DH10A DH10A, THD102KD, THD102KB TAD1030G TAD1030GE TAD1030GE, TAD1031GE TAD1030P TAD1030V TAD1031GE TAD1032GE TD100G-87 TD100G-87, TD1030ME TD100G-87, TD1030VE TD100GG-87 TD100HP-87 TD1010G, TWD1010G TD1030ME TD1030VE THD102KB THD102KD TWD1030ME TWD1031VE TWD1211G |
| Application | Exhaust Manifold and Installation Components Exhaust Pipe Exhaust Pipe: A Exhaust Pipe: B Induction- and Exhaust Manifold Induction- and Exhaust Manifold: A Induction- and Exhaust Manifold: B Induction- and Exhaust Manifold: C Induction- and Exhaust Manifold: TD100HPB87 Repair Kits Repair Kits: A Repair Kits: B Repair Kits: C |
