Turbocharger 3801163
| No. | Part Name | Part Number | Qty | Description |
| 1 | Turbocharger | 3801163 | 1 | |
| 2 | Exhaust pipe | 21033226 | 1 | |
| 3 | Spring washer | 20766219 | 2 | |
| 4 | Spring washer | 20799706 | 10 | |
| 5 | Exhaust manifold | 20860681 | 2 | |
| 6 | Gasket | 20911633 | 3 | |
| 7 | Spacer sleeve | 20766216 | 12 | |
| 8 | Flange screw | 20766217 | 12 | |
| 9 | Stud | 20921238 | 4 | |
| 10 | Gasket | 20559835 | 1 | |
| 11 | Hexagon nut | 20412308 | 4 | |
| 12 | Oil line | 21086727 | 1 | |
| 13 | Hollow screw | 25167 | 2 | |
| 14 | Gasket | 969011 | 4 | |
| 15 | Oil line | 21033967 | 1 | |
| 16 | Plane gasket | 20405790 | 1 | |
| 17 | Flange screw | 984734 | 2 | |
| 18 | O-ring | 20405822 | 1 | |
| 19 | Retainer | 20405789 | 1 | |
| 20 | Flange screw | 20405792 | 1 | |
| 21 | Gasket | 20792408 | 1 | |
| 22 | Flange | 21034013 | 1 | |
| 23 | Flange screw | 20405874 | 4 | |
| 24 | Stud | 20799733 | 4 | |
| 25 | Hexagon nut | 20412308 | 4 | |
| 26 | Exhaust pipe elbow | 21033993 | 1 | |
| 27 | Washer | 20773400 | 4 | |
| 28 | Flange screw | 20405874 | 4 | |
| 29 | Sealing ring | 21034305 | 1 | |
| 30 | Gasket | 21034332 | 2 | |
| 31 | Flange | 21034301 | 1 | |
| 32 | Hexagon screw | 21034319 | 3 | |
| 33 | Hexagon nut | 20882929 | 3 | |
| 34 | Heat shield, branch pipe | 21136738 | 1 | SN10407461- |
| 35 | Sleeve | 21136725 | 2 | |
| 36 | Sleeve | 21136737 | 2 | |
| 37 | Flange screw | 973924 | 2 | |
| 38 | Flange screw | 20412324 | 2 | |
| 39 | Flange screw | 20405792 | 5 | |
| 40 | Adhesive | 21076484 | 1 |
| Item | Part Name | Part No. |
| 1 | Turbocharger 3801163 | 3801163 |
| Details | |
| Engine model | TAD734GE TAD754GE |
| Application | Exhaust Manifold and Turbocharger Exhaust Manifold and Turbocharger. Low Mounted Turbo. Exhaust Outlet Front |
