Oil filter 466634
| No. | Part Name | Part Number | Qty | Description |
| 1 | Oil filter housing, oil filter | 8194717 | 1 | |
| 2 | Gasket | 469487 | 1 | |
| 3 | Oil filter | 466634 | 2 | |
| 4 | Nipple | 466623 | 2 | |
| 5 | Hexagon screw | 955544 | 2 | |
| 7 | Spring washer | 942336 | 4 | |
| 8 | Cap | 842235 | 1 | |
| 9 | Hose clamp | 945754 | 1 | D70B spec.867221. D70B spec.867276-867280,867300,867301 MOXXXXX/17603-. TD70B spec.867281,867282 MOXXXXX/17603-. |
| 10 | Oil cooler | 468035 | 1 | Repl by 1544501 |
| 11 | Plug | 981749 | 1 | |
| 12 | Sealing ring | 469483 | 2 | (422581) |
| 13 | Tensioning band | 1545255 | 1 | Late type |
| 14 | Tensioning band | 1545256 | 1 | (468659) early type |
| 15 | Hexagon screw | 1545257 | 1 | Late type |
| 16 | Stud | 924072 | 2 | |
| 17 | Washer | 976944 | 2 | |
| 18 | Hexagon nut | 955782 | 2 | |
| 19 | Gasket | 468463 | 1 | |
| 20 | Nipple | 422550 | 1 | |
| 21 | Elbow nipple | 942590 | 1 | |
| 22 | Hose | 351574 | 1 | SN2100285979- |
| 22 | Rubber hose | 943369 | 1 | L=165 mm |
| 23 | Hose clamp | 994559 | 8 | |
| 24 | Tube | 467922 | 1 | Cylinder block-oil cooler., SN-2100285978 |
| 24 | Coolant pipe | 1545816 | 1 | SN2100285979- |
| 25 | Hose | 467538 | 1 | MOXXXXX/109942- |
| 26 | Coolant pipe | 848698 | 1 | Oil cooler-water pump. |
| 27 | Hose | 467538 | 1 | MOXXXXX/109942- |
| 28 | Nipple, water pump | 479974 | 1 | (942691) |
| 29 | Flange screw | 942624 | 1 | 5/16UNCx13 |
| 30 | Bracket | 1130611 | 1 | |
| 31 | Spring washer | 940280 | 1 | |
| 32 | Hexagon screw | 955558 | 1 | |
| 33 | Clamp | 952631 | 1 | |
| 34 | Cross recessed screw | 950046 | 2 | |
| 35 | Hexagon screw | 940133 | 1 | |
| 36 | Washer | 955893 | 1 | |
| 37 | Clamp | 952632 | 1 | Late type |
| 38 | Bracket | 965556 | 1 | |
| 39 | Oil pressure pipe, piston cooling | 422819 | 1 | |
| 40 | Gasket | 11998 | 2 | |
| 41 | Gasket | 942703 | 2 | |
| 42 | Hollow screw | 942007 | 2 | (954394) |
| 34A | Bracket | 1545880 | 1 | SN2100285979- |
| 34B | Clamp | 952632 | 1 | Late type |
| 34C | Cross recessed screw | 950046 | 1 | |
| 34D | Washer | 955893 | 1 | |
| 34E | Spring washer | 941906 | 1 | |
| 34F | Hexagon nut | 955825 | 1 | Late type |
| 38A | Hexagon nut | 955825 | 2 | Late type |
| 38B | Washer | 955893 | 2 | |
| 38C | Spring washer | 941906 | 2 |
| Item | Part Name | Part No. |
| 3 | Oil filter 466634 | 466634 |
| Details | |
| Engine model | DH10A, THD102KD, THD102KB TAD1030G TAD1030GE, TAD1031GE, TAD1032GE TAD1030P TAD120BHC TAD120CHC TAD121CHC TAD1240GE, TAD1241GE, TAD1242GE TAD1630P, TWD1630P TAD730G TAD730P TAD730V TD100CHC TD100CRC TD100G-87 TD1010G, TWD1010G TD1030ME, TWD1030ME TD1030VE, TAD1030V, TWD1031VE TD120BHC TD120BRC TD120C TD120G TD120HPP TD121CHC TD121CRC TD121G-87, TWD1210V, TWD1211V, TAD1230V, TWD1230VE, TWD1231VE TD610G, TWD610G TD610M TD610M, TD630ME, TWD630ME, TD730ME, TWD730ME, TWD731ME TD610V, TWD610V TD610V, TWD610V, TD630VE, TWD630VE, TD640VE TD61A, TD61AW TD61ACE, TD61AG, TD61AP, TID61AG TD61AG, TD61AP TD630ME TD630VE TD640VE TD70G TD70G-83 TD710G, TWD710G TD71A, TD71AW, TID71A TD71A, TID71A, TWD710V, TD730VE, TWD731VE TD71A, TID71A, TWD710V, TD730VE, TWD731VE, TAD730V, TWD740VE TD71ACE, TD71AG, TD71AP TD730ME, TWD730ME, TWD731ME TID120FG TID120HPP TID121FG TID61AG TID70G TID71AG, TID71AP TWD1240VE, TAD1241VE, TAD1242VE, TAD1250VE, TAD1251VE, TAD1252VE TWD610P TWD610V TWD630ME TWD630VE TWD710P TWD740GE, TAD740GE, TAD741GE TWD740VE |
| Application | Housing-oil Filter Lubricating System Lubricating System, Angle of Inclination 10° Lubricating System, Angle of Inclination 40° Lubricating System, Angle of Inclination 40°: A Lubricating System, Angle of Inclination 40°: B Lubricating System, Standard Model Lubricating System, Standard Model: A Lubricating System, Standard Model: B LUBRICATING SYSTEM: A LUBRICATING SYSTEM: B LUBRICATING SYSTEM: TID121FP Oil Cooler and Oil Filter Oil Cooler and Oil Filter: A Oil Cooler and Oil Filter: B Oil Filter Oil Filter and Installation Components Oil Filter and Oil Cooler with Installation Components Oil Filter Housing Oil Filter Housing and Installation Components Oil Filter Housing and Oil Filter Oil Filter Housing with Installation Components Oil Filter Housing: A Oil Filter Housing: B Oil Filter Housing: C Oil Filter with Installation Components Oil Filter, Alt. Location Oil Filter, Alternative Location |
