O-ring 948888
| No. | Part Name | Part Number | Qty | Description |
| 1 | Timing gear plate | 8170561 | 1 | Replaced by 21383522 |
| 1 | Timing gear plate | 21383522 | 1 | |
| 2 | Flange screw | 946470 | 17 | |
| 3 | Seal | 20489341 | 1 | |
| 4 | Cover | 3828662 | 1 | (8170237) |
| 5 | Flange screw | 965197 | 4 | |
| 6 | O-ring | 949736 | 1 | |
| 7 | Idler gear | 8170193 | 1 | |
| 8 | Hub | 8170219 | 2 | |
| 9 | Thrust washer | 8170220 | 3 | |
| 10 | Thrust washer | 3184865 | 3 | |
| 11 | Bearing shield | 3184868 | 3 | |
| 12 | Flange screw | 1547886 | 18 | |
| 13 | Idler gear | 8170195 | 1 | |
| 14 | Idler gear | 8170197 | 1 | |
| 15 | Hub | 8170199 | 1 | |
| 16 | Timing gear cover | 20512768 | 1 | Replaced by 20713791 |
| 16 | Timing gear cover | 20713791 | 1 | |
| 17 | Flange screw | 968553 | 1 | L=115mm |
| 18 | Flange screw | 965182 | 3 | |
| 19 | Flange screw | 965183 | 1 | |
| 20 | Flange screw | 965190 | 1 | |
| 21 | Flange screw | 947790 | 2 | |
| 22 | Flange screw | 965223 | 1 | L=75mm |
| 23 | Sealing strip | 20714247 | 1 | (20526706) |
| 24 | Timing gear cover | 8170227 | 1 | |
| 25 | Flange screw | 973096 | 4 | |
| 26 | Flange screw | 947790 | 2 | |
| 27 | Flange screw | 965181 | 1 | |
| 27 | Flange screw | 965217 | 11 | L=65mm |
| 28 | Flange screw | 965183 | 1 | |
| 29 | Driving device | 8193986 | 1 | |
| 31 | O-ring | 967344 | 1 | |
| 32 | Flange screw | 946752 | 1 | |
| 33 | Flange screw | 965190 | 1 | |
| 34 | Flange screw | 3184837 | 1 | For driving device. mounted from the opposite side through the fuel pump. |
| 35 | Cover | 1556208 | 1 | |
| 36 | O-ring | 948888 | 1 | |
| 37 | Flange screw | 946440 | 2 | |
| 38 | Plug | 3964803 | 1 | |
| 39 | Sealing ring | 20555696 | 1 | (421629) |
| 40 | Seal | 3830184 | 1 | |
| 41 | Pivot pin | 1547940 | 1 |
| Item | Part Name | Part No. |
| 36 | O-ring 948888 | 948888 |
| Details | |
| Engine model | TAD1240GE TAD1240GE, TAD1241GE, TAD1242GE TAD1241GE, TAD1242GE TAD1241VE, TAD1242VE TAD1250VE, TAD1251VE, TAD1252VE TAD540-42VE, TAD550-51VE, TAD540VE, TAD541VE, TAD542VE, TAD550VE, TAD551VE, TAD552VE TAD570VE, TAD571VE, TAD572VE TAD840VE, TAD841VE, TAD842VE, TAD843VE, TAD851VE, TAD852VE, TAD853VE, TAD850-52VE, TAD840-43VE TAD870VE, TAD871VE, TAD872VE, TAD873VE TD164KAE TWD1240VE, TAD1241VE, TAD1242VE, TAD1250VE, TAD1251VE, TAD1252VE TWD1643GE TWD1644GE, TWD1645GE TWD1652GE, TWD1653GE TWD1663GE TWD1672GE, TWD1673GE |
| Application | After Cooler and Installation Components Air Compressor 360CC KNORR 1cyl Air Compressor 720CC KNORR 2cyl No Air Compressor Power Steering Pump Power Take off Air Comp Position PTO at power stering pump position Repair Kits Timing Gear Housing Timing Gear Housing, closed front end |
| Specification | |
| Descriptions | For Servo Pump drive when no Air Compressor |
