Baffle plate 844533
| No. | Part Name | Part Number | Qty | Description |
| 1 | Oil pump | 4774185 | 1 | |
| 2 | Baffle | 421404 | 2 | |
| 3 | Hexagon screw | 955538 | 4 | |
| 4 | Delivery pipe | 844542 | 1 | |
| 5 | O-ring | 947061 | 1 | |
| 6 | Hexagon screw | 955524 | 2 | Used on crankshaft 829999. |
| 7 | Spring washer | 941907 | 2 | |
| 8 | Suction pipe | 844558 | 1 | |
| 9 | O-ring | 948229 | 1 | Early type |
| 10 | Hexagon screw | 955524 | 2 | Used on crankshaft 829999. |
| 11 | Spring washer | 941907 | 2 | |
| 12 | Wire gauze | 403483 | 1 | |
| 13 | Snap ring | 118123 | 1 | |
| 14 | Fitting | 466906 | 1 | (940358) |
| 15 | Drain pipe | 844619 | 1 | |
| 16 | O-ring | 844637 | 1 | Truck K250 |
| 17 | Hexagon screw | 944446 | 2 | |
| 18 | Spring washer | 941907 | 2 | |
| 19 | Sump | 821343 | 1 | |
| 20 | Magnetic plug | 192538 | 1 | |
| 21 | Gasket, plug | 18677 | 1 | |
| 22 | Gasket | 420025 | 2 | |
| 23 | Flange screw | 942402 | 33 | |
| 23 | Flange screw | 944012 | 1 | |
| 24 | Oil dipstick | 844626 | 1 | |
| 25 | Tube | 836179 | 1 | AQ120B excl USA MO85861850/XXXX-. BB140A MO85874155/XXXX-. AQ120B USA MO85885755/XXXX-. AQ145A MO85891625/XXXX-. |
| 26 | Reduction valve | 421123 | 1 | |
| 27 | O-ring | 949721 | 1 | (925062) |
| 28 | Hexagon screw | 940100 | 2 | |
| 29 | Spring washer | 941906 | 2 | |
| 30 | Oil filter | 4785974 | 1 | |
| 31 | Nipple | 423067 | 1 | |
| 32 | O-ring | 949656 | 2 | |
| 33 | Oil filter housing | 466339 | 1 | D70B spec. 867276, 867277, 867278, 867279, 867280, 867283, 867300, 867301. TD70B spec. 867281, 867282., See group 3 |
| 34 | Plug | 952075 | 1 | |
| 35 | Hexagon screw | 940115 | 3 | |
| 36 | Spring washer | 942336 | 3 | |
| 37 | Oil cooler | 420365 | 1 | D70B spec.867221. D70B spec.867276-867280,867300,867301 MOXXXXX/17603-. TD70B spec.867281,867282 MOXXXXX/17603-. |
| 38 | Sealing ring | 469483 | 2 | (422581) |
| 39 | Spacer sleeve | 807183 | 1 | Used on crankshaft 829999. |
| 40 | O-ring | 955982 | 1 | AQ120B excl USA MO85861850/XXXX-. BB140A MO85874155/XXXX-. AQ120B USA MO85885755/XXXX-. AQ145A MO85891625/XXXX-. |
| 41 | Outlet pipe | 844565 | 1 | |
| 42 | O-ring | 948229 | 1 | Early type |
| 43 | Hexagon screw | 959795 | 2 | SN2120226440- |
| 44 | Spring washer | 941907 | 2 | |
| 45 | Baffle plate | 844533 | 1 | |
| 46 | Flange screw | 942624 | 2 | 5/16UNCx13 |
| 47 | Hex. socket screw | 956567 | 1 | For engine,40° inclanation. |
| 48 | Flange screw | 942624 | 1 | 5/16UNCx13 |
| Item | Part Name | Part No. |
| 45 | Baffle plate 844533 | 844533 |
| Details | |
| Engine model | TD60B TD60D TD60D-83 TID60D |
| Application | Lubricating System, Angle of Inclination 40° LUBRICATING SYSTEM, ANGLE OF INCLINATION 40°: A LUBRICATING SYSTEM, ANGLE OF INCLINATION 40°: B |
