Bend 837278
| No. | Part Name | Part Number | Qty | Description |
| 1 | Air filter | 823701 | 1 | Late type |
| 2 | Tensioning band | 821028 | 2 | |
| 3 | Clevis pin, threaded | 31404 | 2 | |
| 4 | Pin | 31405 | 2 | |
| 5 | Hexagon screw | 31406 | 2 | |
| 6 | Bracket | 822279 | 2 | D70B early production.D70B classed engine,spec.867053 |
| 7 | Screw | 822953 | 2 | L=93mm |
| 7 | Screw | 822954 | 2 | L=42mm |
| 8 | Hexagon screw | 940159 | 4 | |
| 9 | Spring washer | 941907 | 4 | |
| 10 | Pressure drop indica | 822984 | 1 | MO-XXXXX/18921 |
| 10 | Pressure drop indica | 842037 | 1 | |
| 11 | Nipple | 191095 | 1 | |
| 12 | Tube | 821270 | 1 | |
| 13 | Plug | 16325 | 1 | |
| 14 | Plug | 192114 | 1 | |
| 15 | Gasket | 957185 | 1 | |
| 16 | Hose | 837444 | 1 | MO47461/XXXXX- |
| 17 | Hose | 344008 | 1 | D70B.D70B classed engine spec.867117. |
| 17 | Corrugated hose | 345741 | 1 | Åkerman. |
| 17 | Connecting hook | 824359 | 1 | Std |
| 18 | Hose clamp | 943483 | 2 | (951800) |
| 19 | Hose clamp | 943481 | 1 | (951798) |
| 20 | Bend | 837278 | 1 | D70B spec. 867221., Alt |
| 21 | Hose clamp | 944307 | 1 | D70B spec. 867221., Alt |
| 22 | Hose clamp | 961678 | 1 | D70B spec. 867221., Alt |
| 7A | Spacer sleeve | 807250 | 4 | L=16mm (826652) |
| 11A | Elbow nipple | 16218 | 1 | |
| 11B | Nipple | 823953 | 1 | When oil supervision not is mounted. |
| 18A | Hose clamp | 943484 | 1 | (951801) |
| Item | Part Name | Part No. |
| 20 | Bend 837278 | 837278 |
| Details | |
| Engine model | D70B TD120HPP TD60A TD60B TD60D TD60D-83 TD70B TD70G TD70G-83 TID60D TID60DG TID70G |
| Application | Air Filter and Installation Components Air Filter and Installation Components, Later Production Air Filter and Installation Components: A Air Filter and Installation Components: B |
| Specification | |
| Descriptions | ALT D70B spec. 867221., Alt For engine with outer air inlet pipe., Late type |
