Big-end bearing kit 270124
| No. | Part Name | Part Number | Qty | Description |
| 1 | Cylinder liner kit | 276856 | 6 | |
| 4 | Gudgeon pin | 8194586 | 6 | |
| 5 | Snap ring | 914529 | 12 | |
| 6 | Sealing ring kit | 271157 | 6 | |
| 10 | Piston ring kit | 276851 | 6 | |
| 14 | Crankshaft | 3826010 | 1 | Classified |
| 15 | Woodruff key | 422253 | 1 | |
| 16 | Plug | 978130 | 6 | |
| 17 | Gear | 423080 | 1 | |
| 18 | Connecting rod | 8194037 | 6 | |
| 19 | Bushing | 8194039 | 6 | |
| 20 | Flange screw | 1545479 | 12 | (417464) |
| 21 | Big-end bearing kit | 270124 | 6 | Std D |
| 21 | Big-end bearing kit | 270125 | 6 | 0,25mm u.s |
| 21 | Big-end bearing kit | 270126 | 6 | 0,50mm u.s |
| 21 | Big-end bearing kit | 270127 | 6 | U.S=0,75mm |
| 21 | Big-end bearing kit | 270128 | 6 | U.S=1,00mm |
| 21 | Big-end bearing kit | 270129 | 6 | U.S=1,25mm |
| 22 | Main bearing kit | 270438 | 7 | |
| 22 | Main bearing kit | 270439 | 7 | 0.25mm u.s |
| 22 | Main bearing kit | 270440 | 7 | 0.50mm u.s |
| 22 | Main bearing kit | 270441 | 7 | 0.75mm u.s |
| 22 | Main bearing kit | 270442 | 7 | 1.00mm u.s |
| 22 | Main bearing kit | 270443 | 7 | 1.25mm u.s |
| 23 | Thrust washer kit | 276758 | 1 | Std D |
| 23 | Thrust washer kit | 276759 | 1 | 0,10mm o.s |
| 23 | Thrust washer kit | 276760 | 1 | 0,20mm o.s |
| 23 | Thrust washer kit | 276761 | 1 | 0,30mm o.s |
| 25 | Hub | 425439 | 1 | |
| 26 | Washer | 422124 | 1 | |
| 27 | Hexagon screw | 941494 | 1 | |
| 28 | Vibration damper | 425767 | 1 | |
| 29 | Thrust ring | 425050 | 1 | |
| 30 | Hex. socket screw | 956601 | 6 | Repl by 1pc 829856 4PCS 829857 4PCS 829858 4PCS 941905 4PCS 955780., L=32mm |
| 31 | Adjusting washer | 422619 | 1 | TH=0.20mm |
| 31 | Adjusting washer | 422620 | 1 | TH=0.30mm |
| 31 | Adjusting washer | 422621 | 1 | TH=0.50mm |
| 35 | Sealant | 1161231 | 1 | 304ml |
| 35 | Sealant | 1161277 | 1 | 20g |
| Item | Part Name | Part No. |
| 21 | Big-end bearing kit 270124 | 270124 |
| Details | |
| Engine model | DH10A TAD1030G TAD1030GE TAD1030P TAD1030V TAD1031GE TAD1032GE TD100CHC TD100CRC TD100G TD100G-85 TD100G-87 TD100GG TD100GG-85 TD100GG-87 TD100GP TD100GP-85 TD100HPB-87 TD1010G, TWD1010G TD1030ME TD1030VE THD102KB THD102KD TID100K TID100K-87 TID100KG TID100KG-87 TID100KGP-87 TID100KP TID100KPB-87 TWD1030ME TWD1031VE |
| Application | Crank Mechanism Crank Mechanism: A Crank Mechanism: B Crank Mechanism: C Crankshaft and Related Parts: A Crankshaft and Related Parts: B Crankshaft and Related Parts: C Crankshaft and Related Parts: TD100GGP-87 Crankshaft and Related Parts: TD100HP87 Crankshaft and Related Parts: TID100KP87 Repair Kits Repair Kits: A Repair Kits: B Repair Kits: C Repair Kits: TD100-87 Repair Kits: TID100-87 |
| Specification | |
| Descriptions | MO162079/XXXXX-, Std D Std Std D |
