Big-end bearing kit 270796
| No. | Part Name | Part Number | Qty | Description |
| 1 | Cylinder liner kit | 3826320 | 6 | SN2160022234- |
| 1 | Cylinder liner kit | 3830285 | 6 | |
| 4 | Gudgeon pin | 1556939 | 6 | (1556401) |
| 5 | Snap ring | 914532 | 12 | |
| 6 | Sealing ring kit | 270935 | 6 | |
| 7 | Sealing ring | 1543507 | 6 | |
| 10 | Piston ring kit | 3837146 | 6 | (876831) |
| 14 | Shim | 1548125 | 1 | Shims to adjust the cylinder liner level., TH=0,20mm |
| 14 | Shim | 1548126 | 1 | Shims to adjust the cylinder liner level., TH=0,30mm |
| 14 | Shim | 1548127 | 1 | Shims to adjust the cylinder liner level., TH=0,50mm |
| 15 | Sealant | 1161277 | 1 | 20g |
| 16 | Connecting rod | 1556319 | 6 | SN2160022234- |
| 17 | Flange screw | 1543035 | 12 | |
| 18 | Bushing | 1556321 | 6 | SN2160022234- |
| 19 | Big-end bearing kit | 270796 | 6 | Std D |
| 19 | Big end bearing kit | 270797 | 6 | U.S=0,25mm |
| 19 | Big end bearing kit | 270798 | 6 | U.S=0,51mm |
| 19 | Big end bearing kit | 270799 | 6 | U.S=0,76mm |
| 20 | Crankshaft | 863792 | 1 | |
| 21 | Plug | 978130 | 6 | |
| 22 | Woodruff key | 422253 | 1 | |
| 23 | Pin | 950645 | 1 | |
| 24 | Main bearing kit | 270792 | 7 | Std D |
| 24 | Main bearing kit | 270793 | 7 | U.S=0,25mm |
| 24 | Main bearing kit | 270794 | 7 | U.S=0,51mm |
| 24 | Main bearing kit | 270795 | 7 | U.S=0,76mm |
| 25 | Thrust washer kit | 270929 | 1 | Std D |
| 25 | Thrust washer kit | 270930 | 1 | O.S=0,10mm |
| 25 | Thrust washer kit | 270931 | 1 | O.S=0,20mm |
| 25 | Thrust washer kit | 270932 | 1 | 0,30mm o.s |
| 26 | Gear | 1543444 | 1 | |
| 27 | Flywheel | 889617 | 1 | (3825678) |
| 27 | Flywheel | 3825678 | 1 | (849115) |
| 28 | Ring gear | 20711957 | 1 | |
| 29 | Hexagon screw | 849912 | 14 | |
| 29 | Hexagon screw | 1677893 | 14 | |
| 30 | Washer | 1543563 | 14 | |
| 31 | Hub | 848851 | 1 | |
| 32 | O-ring | 945512 | 1 | |
| 33 | Vibration damper | 8193930 | 2 | |
| 34 | Washer | 422124 | 1 | |
| 35 | Screw | 862504 | 1 | |
| 36 | V-belt pulley, 12-hole | 3825893 | 1 | 3-groove, SN2160018481- |
| 37 | Wear ring | 3829683 | 1 | |
| 38 | Hexagon screw | 973253 | 12 | Earlier production of 6pcs of screw is replaced by 12pcs screw. |
| 39 | Washer | 4956010 | 12 | SN-2160018480 |
| 40 | O-ring | 955974 | 12 | SN-2160018480 |
| 41 | Hub | 3825885 | 1 | |
| 42 | Gasket | 3825886 | 2 | Earlier production of 6pcs of screw is replaced by 12pcs screw. |
| Item | Part Name | Part No. |
| 19 | Big-end bearing kit 270796 | 270796 |
| Details | |
| Engine model | TAD1630G, TAD1630GE TAD1630P TAD1630P, TWD1630P TAD1630V TAD1630V, TWD1630V TAD1631G, TAD1631GE TD164KAE TID162AG, TID162AGP TID162AG, TID162AGP, TID162AP, TID162APB TID162AP, TID162APB TWD1620G TWD1630G TWD1630G, TAD1630G, TAD1630GE, TAD1631G, TAD1631GE TWD1630G, TAD1630G, TAD1631G, TAD1631GE TWD1630P TWD1630V |
| Application | Crank Mechanism Crank Mechanism: SN-2160022233 Crank Mechanism: SN2160022234- Repair Kits |
| Specification | |
| Descriptions | Std Std D |
