Bracket 821058
| No. | Part Name | Part Number | Qty | Description |
| 1 | Oil cooler | 836821 | 1 | Std |
| 2 | Housing | 822212 | 1 | |
| 3 | Insert | 820551 | 1 | |
| 4 | End cover | 823803 | 2 | |
| 5 | Hexagon screw | 942384 | 16 | |
| 6 | Hexagon nut | 955825 | 16 | Late type |
| 7 | O-ring | 925027 | 2 | |
| 8 | Shut-off cock | 82744 | 1 | |
| 9 | Plug | 180759 | 2 | |
| 10 | Clamping ring | 823802 | 2 | |
| 11 | Bracket | 821058 | 1 | |
| 12 | Bracket | 821061 | 1 | |
| 12 | Bracket | 821384 | 2 | D70B classed engine spec.867053 MOXXXXX/5846- |
| 13 | Hexagon screw | 942529 | 4 | |
| 14 | Spring washer | 942336 | 4 | |
| 15 | Hollow screw | 191929 | 3 | Used on crankshaft 826834., Spec 867560 867561 867562 867563 867564 867565., Replaced by 818053. |
| 16 | Hollow screw | 424205 | 1 | |
| 17 | Gasket | 957185 | 8 | |
| 18 | Oil pipe | 823108 | 1 | |
| 19 | Oil pipe | 823109 | 1 | |
| 20 | Clamp | 942421 | 1 | |
| 21 | Anchorage | 821076 | 1 | |
| 22 | Hexagon screw | 955513 | 1 | |
| 23 | Hexagon nut | 955825 | 1 | Late type |
| 24 | Spring washer | 941906 | 1 | |
| 25 | Coolant pipe | 820639 | 1 | |
| 26 | Rubber hose | 943372 | 1 | L=90mm |
| 27 | Hose clamp | 943480 | 6 | MO-XXXXX/98707., (951797) |
| Item | Part Name | Part No. |
| 11 | Bracket 821058 | 821058 |
| Details | |
| Engine model | D100BRC, TD100ARC D120A, TD120A D70B, TD70B D70CRC, TD70CRC TD100CRC TD120ARC TD120BRC TD121CRC |
| Application | Oil Cooler Front End Mounted and Installation Components OIL COOLER FRONT END MOUNTED AND RELATED PARTS Oil Cooler, Front End Mounted and Related Parts Oil Cooler, Front End Mounted with Installation Components |
