Cable block 862489
| No. | Part Name | Part Number | Qty | Description |
| 5 | Sensor, rpm | 862289 | 1 | |
| 6 | O-ring | 925059 | 1 | AQ115A compression 8,4:1. |
| 7 | Temperature sensor, instrument | 862154 | 1 | Max 120°C |
| 8 | Thermo monitor, coolant temp. | 848829 | 1 | 103°C |
| 8 | Thermo monitor, coolant temp. | 862250 | 1 | 97°C |
| 9 | Gasket | 947624 | 2 | |
| 10 | Oil pressure sensor | 862155 | 1 | |
| 11 | Pressure monitor, oil pressure-engine | 863169 | 1 | 0.7bar |
| 14 | Cable block | 862218 | 1 | Cable unit engine. |
| 14 | Cable block | 862489 | 1 | Replaced by 1pc cable unit 863815 and 1pc adepter 863227., Cable unit engine., Spec.868067 |
| 14 | Cable harness | 863815 | 1 | Cable unit engine., Spec.868067 |
| 15 | Adapter | 863227 | 1 | Early type |
| Item | Part Name | Part No. |
| 14 | Cable block 862489 | 862489 |
| Details | |
| Engine model | TD100G-87 TD121G-87 TID121L-87 |
| Application | Electrical System and Instruments: A |
| Specification | |
| Descriptions | Replaced by 1pc cable unit 863815 and 1pc adepter 863227., Cable unit engine., Spec.868067 Replaced by 1pc cable unit 863815 and 1pc adepter 863227., Cable unit engine., Spec.868075 Replaced by 1pc cable unit 863815 and 1pc adepter 863227., Cable unit engine., Spec.868172 |
