Cable terminal 849959
| No. | Part Name | Part Number | Qty | Description |
| 1 | Electric cable, 5 sq mm black | 954443 | 1 | |
| 1 | Electric cable, 5 sq mm brown | 954444 | 1 | |
| 1 | Electric cable, 5 sq mm red | 954445 | 1 | |
| 1 | Electric cable, 5 sq mm yellow | 954446 | 1 | |
| 1 | Electric cable, 5 sq mm green | 954447 | 1 | |
| 1 | Electric cable, 5 sq mm blue | 954448 | 1 | |
| 1 | Electric cable, 5 sq mm grey | 954449 | 1 | |
| 1 | Electric cable, 5 sq mm ivory | 954450 | 1 | |
| 1 | Electric cable, 5 sq mm black | 954451 | 1 | |
| 1 | Electric cable, 5 sq mm brown | 954452 | 1 | |
| 1 | Electric cable, 5 sq mm red | 954453 | 1 | |
| 1 | Electric cable, 5 sq mm green | 954455 | 1 | |
| 1 | Electric cable, 5 sq mm blue | 954456 | 1 | |
| 1 | Electric cable, 5 sq mm ivory | 954458 | 1 | |
| 1 | Electric cable | 954461 | 1 | |
| 1 | Electric cable | 954463 | 1 | |
| 1 | Electric cable | 954464 | 1 | |
| 1 | Electric cable | 954465 | 1 | |
| 1 | Electric cable | 954467 | 1 | |
| 1 | Electric cable | 954469 | 1 | |
| 1 | Electric cable | 954471 | 1 | |
| 1 | Electric cable, type RK | 954485 | 1 | 16,0mm², red |
| 1 | Electric cable, type RK | 954500 | 1 | 25,0mm², red |
| 1 | Electric cable, type RK | 954502 | 1 | 35,0mm², red |
| 1 | Electric cable, cable | 961792 | 1 | RK 1,5mm² |
| 1 | Electric cable, cable | 961794 | 1 | RK 1,5mm² |
| 1 | Electric cable, 5 sq mm ivory1 blue | 961795 | 1 | |
| 1 | Electric cable, cable | 961798 | 1 | RK 1,5mm² |
| 1 | Electric cable, cable | 961800 | 1 | RK 1,5mm² |
| 1 | Electric cable, cable | 964131 | 1 | |
| 1 | Electric cable, cable | 964132 | 1 | RK 0,75mm² |
| 1 | Electric cable, cable | 964135 | 1 | RK 0,75mm² |
| 1 | Electric cable, cable | 964136 | 1 | RK 0,75mm² |
| 1 | Electric cable, cable | 964142 | 1 | RK 1,5mm² |
| 1 | Electric cable | 965754 | 1 | RK 1,5mm², purple |
| 2 | Cable | 842090 | 1 | Non reinforced ship cable approved by classification societies., 16,0mm², red |
| 2 | Cable | 842091 | 1 | 2X1,5SQMM |
| 2 | Cable | 842092 | 1 | Non reinforced ship cable approved by classification societies., 3x1,5mm² |
| 2 | Cable | 842093 | 1 | 7X1,5mm² class |
| 2 | Cable | 843084 | 1 | 12X1,5SQMM |
| 2 | Cable | 843085 | 1 | 3X16mm² class |
| 2 | Cable | 844578 | 1 | 4X2,5mm² class |
| 2 | Cable | 846273 | 1 | 4X1,5mm² class |
| 2 | Cable | 846345 | 1 | 2X6+2X1,5mm² class |
| 2 | Cable | 846346 | 1 | Replaced by wiring harness 872679 and adapter 872939 |
| 2 | Electric cable | 846639 | 1 | Non reinforced ship cable approved by classification societies., 2x1,5mm² |
| 3 | Hose | 185501 | 1 | D=9mm, i.d=8mm |
| 3 | Hose | 185506 | 1 | D=6mm, i.d=5mm |
| 3 | Hose | 185507 | 1 | D=11mm, i.d=10mm |
| 3 | Outer casing | 185509 | 1 | D=19mm, i.d=15mm |
| 3 | Hose | 949988 | 1 | D=11,5mm, i.d=8mm |
| 4 | Cable rating | 899751 | 1 | For ground wire, For cable area 1-2,5mm² |
| 5 | Cable tie | 335146 | 1 | Al |
| 5 | Cable tie | 948210 | 1 | (827353) |
| 6 | Terminal block | 942558 | 1 | |
| 6 | Terminal block | 942659 | 1 | |
| 6 | Terminal block | 942660 | 1 | |
| 6 | Terminal block | 942661 | 1 | |
| 6 | Terminal block | 942662 | 1 | |
| 7 | Coupling piece | 182010 | 1 | Max 15mm² |
| 7 | Coupling piece | 190128 | 1 | Max 15mm² |
| 7 | Coupling piece | 926219 | 1 | Black |
| 7 | Coupling piece | 941412 | 1 | Max 20mm² |
| 8 | Cable terminal | 956924 | 1 | Spec. 867057, 867058, 867059, 867279., I.d=3,7mm D=5,6mm |
| 8 | Cable terminal | 956927 | 1 | For cable area 1,5-2,5mm²., I.d=3,7mm D=17mm |
| 8 | Cable terminal | 956928 | 1 | For cable area 1,5-2,5mm²., I.d=4,3mm D=18mm |
| 9 | Cable terminal | 881492 | 1 | M4x1,1-2,5mm² |
| 9 | Cable terminal | 881493 | 1 | M5x1,1-2,5mm² |
| 9 | Cable terminal | 881494 | 1 | M8x1,1-2,5mm² |
| 9 | Cable terminal | 881495 | 1 | M5x2,6-6,0mm² |
| 9 | Cable terminal | 881496 | 1 | M6x2,6-6,0mm² |
| 9 | Cable terminal | 881497 | 1 | M8x2,6-6,0mm² |
| 9 | Cable terminal | 881498 | 1 | M10x2,6-6,0mm² |
| 9 | Cable terminal | 881506 | 1 | M4x2,6-6,0mm² |
| 9 | Cable terminal | 881508 | 1 | M6x1,1-2,5mm² |
| 9 | Cable terminal | 881516 | 1 | Spec. 867057, 867058, 867059, 867279., I.d=3,5mm D=5,5mm |
| 9 | Cable terminal | 881519 | 1 | For cable area 2,7-6,6mm², I.d=3,7mm D=7,1mm |
| 9 | Cable terminal | 940333 | 1 | M8x6,1-10,0mm² |
| 9 | Cable terminal | 940335 | 1 | M6x10,1-16,0mm² |
| 9 | Cable terminal | 940336 | 1 | M8x10,1-16,0mm² |
| 9 | Cable terminal | 940337 | 1 | M10x10,1-16,0mm² |
| 9 | Cable terminal | 949591 | 1 | D70B spec.867060. TD70B spec.867066early production., I.d=4,3mm D=8mm |
| 9 | Cable terminal | 958235 | 1 | FOR CABLE AREA 10,5-16,0 SQMM., (881500) |
| 10 | Cable terminal | 11426 | 1 | For cable area 0,75-2,5mm², I.d=4,5mm D=8mm |
| 11 | Cable terminal | 881483 | 1 | 6,3x0,8x1,1-2,5mm² |
| 11 | Cable terminal | 881484 | 1 | 6,3x0,8x4,0-6,0mm² |
| 11 | Cable terminal | 949210 | 1 | For cable area 0,75-1mm², L=7,4mm b=6,5mm |
| 11 | Cable terminal | 949404 | 1 | For cable area 1-2,5mm², L=6,4mm b=5,6mm |
| 12 | Cable terminal | 881485 | 1 | Spec. 867494, 867648., L=7,7mm b=7,6mm |
| 12 | Cable terminal | 881486 | 1 | SEV Motorola 26692., L=7,7mm b=7,6mm |
| 12 | Cable terminal | 949204 | 1 | For cable area 1-2,5mm², L=7,7mm b=7,4mm |
| 13 | Cable terminal | 881491 | 1 | 6,3x0,75-2,1mm² |
| 13 | Cable terminal | 941730 | 1 | For cable area 1,5-2,5mm²., L=7,7mm b=6,4mm |
| 15 | Cable terminal | 881489 | 1 | 6,3x0,8x1,1-2,5 |
| 16 | Cable terminal | 881505 | 1 | Spec. 867494, 867648., I.d=5,2mm D=8,7mm |
| 16 | Cable terminal | 881509 | 1 | Spec. 867494, 867648., I.d=4,4mm D=9,8mm |
| 16 | Cable terminal | 881511 | 1 | SEV Motorola 26692., I.d=4,4mm D=8mm |
| 17 | Cable terminal | 881487 | 1 | 6,3x0,8x0,75-2,5mm² |
| 17 | Cable terminal | 881488 | 1 | 6,3x0,8x4,0-6,0mm² |
| 17 | Cable terminal | 943799 | 1 | For cable area 16mm²., L=8mm b=6,3mm |
| 18 | Cable terminal | 881518 | 1 | |
| 19 | Tab | 839328 | 1 | 16,3x6,3x0,8 |
| 20 | Tab | 829311 | 1 | I.d=5,2mm b=6,35mm |
| 20 | Cable terminal, flat pin | 941090 | 1 | I.d=4,1mm b=6,3mm |
| 20 | Cable terminal | 941449 | 1 | I.d=3,7mm b=6,3mm 9 |
| 20 | Cable terminal | 942888 | 1 | I.d=5,2mm b=6,3mm45 |
| 20 | Cable terminal | 944485 | 1 | 6,3xM5x180 |
| 21 | Cable terminal | 942429 | 1 | For 853866, Yasaki |
| 22 | Cable terminal | 849959 | 1 | |
| 23 | Cable terminal | 849958 | 1 | 1,6x0,5-1,5mm² |
| 24 | Cable terminal | 965824 | 1 | 3,5x1,1-2,5mm² |
| 25 | Clip, battery cable +pole | 844280 | 1 | 16x1,5mm² |
| 26 | Cable terminal, battery cable -pole | 954505 | 1 | D=77mm L=280mm |
| 27 | Splice | 956956 | 1 | D=102mm L=362mm |
| 27 | Splice | 956958 | 1 | 1,5-2,5mm², blue |
| 27 | Splice | 956960 | 1 | L=61mm |
| 28 | Housing | 944221 | 1 | 6,3x1 natural |
| 29 | Tape | 858283 | 1 | 4x2,5mm² |
| Item | Part Name | Part No. |
| 22 | Cable terminal 849959 | 849959 |
| Details | |
| Engine model | D70CHC, D70CRC, TD70CHC, TD70CRC TAD1140VE, TAD1141VE, TAD1142VE TAD1150VE, TAD1151VE, TAD1152VE TAD1170VE, TAD1171VE, TAD1172VE TAD1240GE, TAD1241GE, TAD1242GE TAD1340VE, TAD1341VE, TAD1342VE, TAD1343VE, TAD1344VE, TAD1345VE, TAD1360VE, TAD1361VE, TAD1362VE, TAD1363VE, TAD1364VE, TAD1365VE TAD1350VE TAD1351VE, TAD1352VE, TAD1353VE TAD1352VE TAD1360VE TAD1361VE TAD1363VE TAD1371VE, TAD1372VE, TAD1373VE, TAD1374VE, TAD1375VE TAD1640GE, TAD1641GE, TAD1642GE, TAD1650GE, TAD1651GE, TWD1643GE, TWD1652GE, TWD1653GE, TWD1663GE TAD1641VE, TAD1642VE, TAD1643VE, TAD1650VE, TAD1660VE, TAD1661VE, TAD1662VE, TAD1640VE-B, TAD1641VE-B, TAD1642VE-B, TAD1660-62VE, TAD1662VE EU5 TAD1643VE-B TAD1650VE-B, TAD1651VE TAD1670VE, TAD1671VE, TAD1672VE TAD940GE, TAD941GE TAD940VE, TAD941VE, TAD942VE, TAD943VE, TAD950VE, TAD951VE, TAD952VE TD100CHC, TD100CRC, TD121CHC, TD121CRC, TAD121CHC TD100G, TD100HP-87, TID100K TD120HP-86, TD121G, TID121K, TID121L-87 TD120HP-86, TID121KP, TID121LP TD121G, TD121GG, TD121GG-86, TID121K, TID121KG, TID121LG TD30A, TD31ACE, TD40A, TD45B, D45A TD520VE, TD720VE TD61A, TD61AW, TD61ACE, TD61AG, TD61AGP, TD61AP, TD61APB, TID61AG, TD71A, TD71AW, TD71ACE, TD71AG, TD71AGP, TD71AP, TD71APB, TID71A, TID71AG, TID71AGP, TID71AP, TID71APB, TID61AGP TD61A, TD61AW, TD61AG, TID61AG, TD71A, TD71AW, TD71AG, TID71A, TID71AG TD61AP, TD71AP, TID71AP TID121FG TWD1240VE, TAD1241VE, TAD1242VE, TAD1250VE, TAD1251VE, TAD1252VE TWD1620G, TWD1630G, TAD1630G, TAD1630GE, TAD1631G, TAD1631GE TWD1644GE, TWD1645GE TWD1672GE, TWD1673GE |
| Application | Cables and Terminals Electrical Box and Installation Components ELECTRICAL BOX AND INSTALLATION COMPONENTS: B ELECTRICAL BOX AND INSTALLATION COMPONENTS: TID121FP Electrical Materials |
| Specification | |
| Descriptions | (847041) For 846612 |
