Clamp 952630
| No. | Part Name | Part Number | Qty | Description |
| 1 | Housing | 843686 | 1 | |
| 2 | Cap | 844039 | 1 | |
| 3 | Gasket | 844041 | 1 | |
| 4 | Cover | 843687 | 1 | |
| 5 | Gasket | 843690 | 1 | |
| 6 | Hexagon screw | 955272 | 8 | |
| 7 | Spring washer | 941906 | 8 | |
| 8 | Bracket | 844126 | 1 | |
| 9 | Hexagon screw | 940162 | 2 | MO-XXXXX/105194 |
| 10 | Spring washer | 942336 | 2 | |
| 11 | Hexagon screw | 955295 | 1 | |
| 12 | Hex. socket screw | 959220 | 1 | |
| 12 | Hex. socket screw | 959222 | 1 | L = 25 MM |
| 13 | Spring washer | 941907 | 3 | |
| 14 | Piston | 845597 | 1 | EARLY TYPE |
| 15 | Sensor | 827150 | 1 | AQ200D MO-11576, AQ225D MO-11736, AQ260A MO-11506, AQ290A MO-12259., Late type |
| 16 | Flow monitor | 843756 | 1 | EARLY TYPE |
| 17 | Lock nut | 843640 | 1 | |
| 18 | Gasket | 957181 | 1 | |
| 19 | Nipple | 843688 | 1 | |
| 20 | Gasket | 15304 | 1 | |
| 21 | Thermo monitor | 843769 | 1 | STOP |
| 22 | Thermo monitor | 843767 | 1 | ALARM |
| 23 | Gasket | 957179 | 2 | For governor 225-1200. |
| 24 | Sleeve | 843288 | 2 | |
| 25 | Cross recessed screw | 956063 | 3 | |
| 26 | Tube | 844268 | 1 | |
| 27 | Hollow screw | 25167 | 4 | |
| 28 | Gasket | 957178 | 8 | |
| 29 | Nipple | 844127 | 1 | SPEC. 867131., SEE GROUP 3 |
| 30 | Tube | 844277 | 1 | |
| 32 | Gasket | 957183 | 1 | |
| 33 | Nipple | 844127 | 1 | SPEC. 867131., SEE GROUP 3 |
| 34 | Clamp | 942542 | 1 | |
| 35 | Grommet | 881191 | 1 | Early type |
| 36 | Grommet | 881193 | 1 | Replaced by 1 alterator 841765 and 1 cable unit 841822. |
| 37 | Flow monitor | 846622 | 1 | LATE TYPE |
| 38 | Nipple | 846632 | 1 | LATE TYPE |
| 39 | Gasket | 18671 | 1 | |
| 40 | Nipple | 844127 | 1 | SPEC. 867131., SEE GROUP 3 |
| 41 | Grommet | 822327 | 1 | |
| 42 | Clamp | 952630 | 7 | D = 17.5 MM LATE TYPE |
| 42 | Clamp | 952633 | 4 | D = 22.2 MM LATE TYPE |
| 42 | Clamp | 952637 | 2 | D = 25.4 MM LATE TYPE |
| 42 | Clamp | 952641 | 8 | D = 34.9 MM LATE TYPE |
| Item | Part Name | Part No. |
| 42 | Clamp 952630 | 952630 |
| Details | |
| Engine model | D100BHC D100BRC D70CHC D70CRC DH10A TAD1140VE, TAD1141VE, TAD1142VE TAD1150VE, TAD1151VE, TAD1152VE TAD1170VE, TAD1171VE, TAD1172VE TAD120AHC TAD120BHC TAD120CHC TAD121CHC TAD1640GE, TAD1641GE, TAD1642GE TAD1640GE, TAD1641GE, TAD1642GE, TAD1650GE, TAD1651GE TAD1641VE, TAD1642VE TAD1641VE, TAD1642VE, TAD1643VE TAD1650VE TAD740GE TAD741GE TD100AHC TD100ARC TD100CHC TD100CRC TD120AHC TD120ARC TD120BHC TD120BRC TD121CHC TD121CRC TD70CHC TD70CRC TD70G TD70G-83 TID70G TWD740GE |
| Application | Coolant Supervision and Installation Components Coolant Supervision and Installation Components: A Coolant Supervision and Installation Components: B COOLANT SUPERVISION WITH INSTALLATION COMPONENTS: A COOLANT SUPERVISION WITH INSTALLATION COMPONENTS: B COOLANT SUPERVISION WITH INSTALLATION COMPONENTS: C COOLANT SUPERVISION WITH INSTALLATION COMPONENTS: D Electric system, engine wiring harness Fuel Injection Pump and Fuel Filter. Standard Fuel System: A Fuel Injection Pump and Fuel Filter. Standard Fuel System: B Fuel Injection Pump and Fuel Filter. Standard Fuel System: C Fuel System Lubricating System, Angle of Inclination 10° Lubricating System, Angle of Inclination 40° Lubricating System, Angle of Inclination 40°: A Lubricating System, Angle of Inclination 40°: B Lubricating System, Standard Model Lubricating System, Standard Model: A Lubricating System, Standard Model: B Radiator with Connecting Components. Pushing Fan. SN-2016028724 Radiator with Connecting Components. Pushing Fan. SN2016028725-2016079647 Radiator with Connecting Components. Suction Fan. SN-2016028724 Radiator with Connection Components. Pusher Fan SN-2016079647 |
| Specification | |
| Descriptions | D = 17.5 MM LATE TYPE D=17.5mm D=17.5mm late type Late type, D=17,5mm |
