Connecting pipe 847260
| No. | Part Name | Part Number | Qty | Description |
| 1 | Inlet pipe | 8193866 | 1 | (478331) |
| 2 | Hexagon screw | 940113 | 1 | |
| 2 | Plug | 960631 | 1 | |
| 3 | Gasket | 11996 | 1 | |
| 3 | Gasket | 957171 | 1 | |
| 4 | Flange screw | 942624 | 1 | 5/16UNCx13 |
| 4 | Hexagon screw | 955527 | 6 | |
| 4 | Hexagon screw | 955530 | 3 | |
| 4 | Hexagon screw | 959795 | 2 | SN2120226440- |
| 5 | Washer | 955894 | 12 | |
| 6 | Connecting pipe | 847260 | 1 | |
| 7 | Starter element | 471867 | 1 | |
| 8 | Hexagon screw | 955532 | 4 | Only for thermoswitch control 837500,837501., L=95mm |
| 9 | Spring washer | 941907 | 4 | |
| 10 | Washer | 955894 | 4 | |
| 11 | Plug | 479979 | 1 | |
| 12 | Gasket kit, induction manifold | 876956 | 1 | (876404) see group 99 |
| 13 | Gasket | 424618 | 2 | |
| 14 | O-ring | 469830 | 6 |
| Item | Part Name | Part No. |
| 6 | Connecting pipe 847260 | 847260 |
| Details | |
| Engine model | TD120HPP TD1210G TD121G-87 TD121GP-87 |
| Application | Induction Manifold with Starter Element Induction- and Exhaust Manifold Inlet Manifold and Starter Element. High Mounted Turbo |
