Connector 3808387
| No. | Part Name | Part Number | Qty | Description |
| 1 | Inlet manifold | 3887300 | 1 | |
| 2 | Sealant | 1161231 | 1 | 304ml |
| 2 | Sealant | 1161277 | 1 | 20g |
| 3 | Flange screw | 984741 | 8 | L=70mm |
| 4 | Plug | 960628 | 1 | |
| 5 | Gasket | 947281 | 1 | |
| 6 | Plug | 479979 | 1 | |
| 7 | Flange screw | 984744 | 4 | |
| 8 | Exhaust manifold | 11447007 | 1 | SN2016010025- |
| 8 | Exhaust manifold | 17203922 | 1 | Order also bracket 23084660 |
| 10 | Exhaust manifold | 20901584 | 2 | |
| 11 | Sealing kit | 20938964 | 2 | (20883460), For 11447007 |
| 12 | Sealing ring | 21695684 | 2 | For 11447007 |
| 13 | Plane gasket | 20784537 | 1 | |
| 14 | Gasket | 20744865 | 6 | (8131215) |
| 15 | Spacer sleeve | 1546517 | 24 | |
| 16 | Flange screw | 984760 | 24 | |
| 17 | Gasket | 477314 | 1 | |
| 18 | Adapter | 3819105 | 1 | Replaced by 23116796 |
| 18 | Adapter | 23116796 | 1 | |
| 19 | Starter element | 3886863 | 1 | |
| 20 | Hex. socket screw | 963702 | 4 | |
| 21 | Connector | 3808387 | 1 | |
| 22 | O-ring | 3812484 | 2 | |
| 23 | Plug | 968063 | 1 |
| Item | Part Name | Part No. |
| 21 | Connector 3808387 | 3808387 |
| Details | |
| Engine model | TWD1643GE TWD1643GE, TWD1652GE, TWD1653GE, TWD1663GE TWD1652GE, TWD1653GE TWD1663GE TWD1672GE, TWD1673GE |
| Application | After Cooler and Installation Components Intake and Exhaust Manifold SN-2016103090 Intake and Exhaust Manifold SN-2016103150 Intake and Exhaust Manifold SN2016103151- |
Related Products
Tags: Connector, Volvo Penta, 3808387
