Coolant pipe 846465
| No. | Part Name | Part Number | Qty | Description |
| 1 | Water pump | 844635 | 1 | Repl by 875653 |
| 1 | Water pump | 875653 | 1 | |
| 1 | Coolant pump | 3803209 | 1 | |
| 3 | Shaft | 422148 | 1 | |
| 4 | Wear ring | 421306 | 1 | |
| 5 | Sealing ring | 1545283 | 1 | (1542833) |
| 6 | Deflector | 70913 | 1 | |
| 7 | Ball bearing | 181670 | 1 | |
| 8 | Ball bearing | 181538 | 1 | |
| 9 | Spacer sleeve | 422202 | 1 | |
| 10 | Ball bearing | 11013 | 1 | |
| 11 | Retaining ring | 914462 | 1 | |
| 12 | Seal | 420162 | 1 | |
| 13 | Gasket | 4773570 | 1 | |
| 14 | Gasket | 4773571 | 1 | |
| 15 | Spacer | 4773467 | 1 | |
| 16 | Hexagon screw | 940161 | 6 | For engine with 40° angle of inclination, L=45mm |
| 17 | Spring washer | 941907 | 6 | |
| 18 | Pulley | 844634 | 1 | Included in water pump 844635. |
| 19 | Hub | 466286 | 1 | MOXXXXX/98708-. |
| 19 | Fan hub | 844136 | 1 | |
| 20 | Hexagon screw | 940135 | 4 | |
| 20 | Hexagon screw | 940159 | 4 | |
| 21 | Washer | 955894 | 4 | |
| 22 | Hex. socket screw | 956569 | 2 | |
| 23 | Gasket | 947620 | 2 | (233321) |
| 24 | Hexagon screw | 940136 | 1 | |
| 24 | Hexagon screw | 940186 | 1 | |
| 24 | Hexagon screw | 955526 | 1 | MD70BK spec 867116 MOXXXX/9685- |
| 25 | Intermediate lever | 466753 | 1 | |
| 26 | Stud | 953353 | 1 | |
| 27 | Spring washer | 941911 | 1 | |
| 28 | Hexagon nut | 955828 | 1 | |
| 29 | Retaining ring | 914533 | 1 | |
| 30 | Ball bearing | 181538 | 1 | |
| 30 | Ball bearing | 1544092 | 1 | (181430) |
| 31 | V-belt pulley | 411670 | 1 | MO-24392/XXXX |
| 32 | Retaining ring | 914462 | 1 | |
| 33 | Protecting plate | 420416 | 1 | |
| 34 | Hexagon screw | 955539 | 2 | |
| 35 | Spring washer | 942336 | 2 | |
| 36 | Gasket | 420160 | 1 | |
| 37 | Flange | 421159 | 1 | |
| 38 | Gasket | 421160 | 2 | |
| 39 | Hexagon screw | 955539 | 2 | |
| 40 | Hexagon screw | 955537 | 2 | |
| 41 | Spring washer | 942336 | 4 | |
| 42 | Cover | 421161 | 1 | |
| 43 | Gasket | 421160 | 1 | |
| 44 | Hexagon screw | 955535 | 2 | |
| 45 | Spring washer | 942336 | 2 | |
| 46 | Plug | 952077 | 3 | |
| 47 | Gasket | 957179 | 3 | For governor 225-1200. |
| 48 | Inlet pipe | 843328 | 1 | |
| 49 | Plug | 952077 | 1 | |
| 50 | O-ring | 925069 | 1 | |
| 51 | Hexagon screw | 940135 | 2 | |
| 52 | Spring washer | 941907 | 2 | |
| 53 | Thermostat housing | 465052 | 1 | |
| 54 | Flange | 843908 | 1 | |
| 55 | O-ring | 949658 | 1 | (925061) early type |
| 56 | Hexagon screw | 955524 | 2 | Used on crankshaft 829999. |
| 57 | Spring washer | 941907 | 2 | |
| 58 | Plug | 952077 | 1 | |
| 59 | Thermostat kit | 875787 | 2 | 76° |
| 59 | Thermostat kit | 875788 | 2 | 70° |
| 60 | Sealing ring | 416033 | 2 | |
| 61 | Tube | 420155 | 1 | |
| 62 | Hexagon screw | 940162 | 3 | MO-XXXXX/105194 |
| 63 | Spring washer | 942336 | 3 | |
| 64 | Temperature sensor | 824552 | 1 | See group 3 |
| 64 | Temperature sensor | 844080 | 1 | D42A PP spec 16053. |
| 65 | Gasket | 11996 | 1 | |
| 67 | V-belt | 949312 | 1 | |
| 68 | Pipe elbow | 820800 | 1 | |
| 69 | Gasket | 420171 | 1 | |
| 70 | Hex. socket screw | 956570 | 1 | |
| 70 | Hex. socket screw | 956571 | 1 | SEE GROUP 2B |
| 71 | Radiator hose | 821128 | 1 | |
| 72 | Spring washer | 941907 | 2 | |
| 73 | Hose clamp | 943480 | 2 | MO-XXXXX/98707., (951797) |
| 74 | Coolant pipe | 846465 | 1 | LMW |
| 75 | Plug | 952077 | 1 | |
| 76 | Hexagon screw | 955530 | 1 | |
| 77 | Spring washer | 941907 | 1 | |
| 78 | Spacer sleeve | 833243 | 1 | |
| 79 | Spacer sleeve | 823492 | 1 | |
| 79 | Rope | 875654 | 1 | |
| 31A | Pulley | 4773755 | 1 | MO39263/XXXXX- |
| 31B | O-ring | 925091 | 1 | |
| 31C | Protecting casing | 4773754 | 1 | MO39263/XXXXX- |
| 31D | Hexagon screw | 955244 | 4 | |
| 31E | Spring washer | 941905 | 4 | Replaced by 1306630, AQ125A USA MO-7545816/XXXX. AQ125A MO-7546500/XXXX. |
| 54A | Connecting pipe | 845435 | 1 | Replaced by 842427, 842428, 842429, 842423, 411710., Late type |
| 54B | Plastic plug | 845422 | 1 | Replaced by 842427, 842428, 842429, 842423, 411710., Late type |
| 54C | Hose clamp | 994560 | 1 | |
| 64A | Plug | 180761 | 1 |
| Item | Part Name | Part No. |
| 74 | Coolant pipe 846465 | 846465 |
| Details | |
| Engine model | TD60B TD60D TD70G TD70G-83 TID70G |
| Application | Circulation Pump and Thermostat with Installation Components: B THERMOSTAT AND WATER PUMP WITH INSTALLATION COMPONENTS Thermostat and Water Pump with Installation Components: A Thermostat and Water Pump with Installation Components: B |
| Specification | |
| Descriptions | (844848) LMV LMW |
