Coolant pump 3801244
| No. |
Part Name |
Part Number |
Qty |
Description |
| 1 |
Thermostat housing |
21883641 |
1 |
SN-11049066 |
| 1 |
Thermostat housing |
22058773 |
1 |
SN11049067- |
| 2 |
Gasket |
21142470 |
1 |
|
| 3 |
Thermostat |
21360430 |
1 |
86°C |
| 4 |
Sealing ring |
20798938 |
1 |
Replaced by 22569028 |
| 4 |
Attachment kit |
22569028 |
1 |
|
| 5 |
Gasket |
20794103 |
1 |
|
| 6 |
Gasket |
993407 |
1 |
|
| 7 |
Plug |
20459195 |
1 |
|
| 8 |
Adapter |
20799929 |
1 |
|
| 9 |
Branch pipe |
21142457 |
1 |
|
| 10 |
Flange screw |
994386 |
2 |
|
| 11 |
Flange screw |
984740 |
4 |
|
| 12 |
Gasket |
11996 |
1 |
|
| 13 |
Hose connection |
21039391 |
1 |
|
| 15 |
Adapter |
20799907 |
1 |
Replaced by 21364517 |
| 16 |
O-ring |
20799129 |
1 |
|
| 17 |
O-ring |
20799131 |
1 |
|
| 18 |
Plug |
21364517 |
1 |
|
| 19 |
Coolant pump |
3801244 |
1 |
|
| 20 |
Gasket |
21632658 |
1 |
|
| 21 |
Flange screw |
20460124 |
7 |
|
| 22 |
Bracket |
21033221 |
1 |
|
| 23 |
Flange screw |
984733 |
15 |
|
| 24 |
Ring |
21567798 |
1 |
SN11049067-, Replaced by 22569028 |
| 24 |
Attachment kit |
22569028 |
1 |
|
| Item |
Part Name |
Part No. |
| 19 |
Coolant pump 3801244 |
3801244 |
| Details |
| Engine model |
TAD734GE |
| Application |
Water Pump and Thermostat Housing |
