Coolant pump 3803930
| No. | Part Name | Part Number | Qty | Description |
| 2 | Flange screw | 984740 | 6 | |
| 3 | Hose nipple | 977508 | 1 | |
| 4 | Pump unit | 3161436 | 1 | |
| 4 | Coolant pump | 3803930 | 1 | |
| 5 | Coolant pump housing | 3808593 | 1 | |
| 6 | Draining nipple | 3583822 | 1 | |
| 7 | Rubber moulding | 8131097 | 1 | Replaced by 21415427 |
| 8 | Plastic plug | 20464402 | 1 | |
| 9 | Flange screw | 946472 | 6 | |
| 10 | Flange screw | 984733 | 1 | |
| 11 | Cover | 20405125 | 1 | Replaced by 21519562 |
| 12 | Flange screw | 973924 | 4 | |
| 13 | Thermostat | 20560249 | 1 | 82°C |
| 14 | Connection pipe | 20555313 | 1 | |
| 15 | Flange screw | 973924 | 5 | |
| 16 | Sealing strip | 20479636 | 1 | |
| 17 | Coolant pipe | 3838856 | 1 | |
| 18 | Sealing ring | 1547252 | 1 | |
| 19 | Coolant pipe | 3836307 | 1 | Replaced by 21253761 |
| 19 | Coolant pipe | 21253761 | 1 | |
| 20 | Sealing ring | 1547254 | 2 | |
| 21 | Connection pipe | 20451178 | 1 | Replaced by 21021925 |
| 22 | Flange screw | 984744 | 2 | |
| 23 | Sealing ring | 1547254 | 1 | |
| 24 | Coolant pipe | 3943401 | 1 | |
| 25 | Flange screw | 984734 | 2 | |
| 26 | O-ring | 975675 | 1 | |
| 27 | Coolant pipe | 3837738 | 1 | |
| 28 | Sealing ring | 1547253 | 1 | |
| 29 | Hose clamp | 994559 | 2 | |
| 30 | Hose | 21339891 | 1 | L=130mm |
| 31 | Plastic plug | 845422 | 2 | Replaced by 842427, 842428, 842429, 842423, 411710., Late type |
| 32 | Flange screw | 984738 | 1 | |
| 33 | Hose clamp | 943472 | 2 | |
| 34 | Rubber moulding | 20430678 | 1 | |
| 35 | O-ring | 975675 | 1 |
| Item | Part Name | Part No. |
| 4 | Coolant pump 3803930 | 3803930 |
| Details | |
| Engine model | TAD940GE, TAD941GE TAD940VE, TAD941VE, TAD942VE, TAD943VE, TAD950VE, TAD951VE, TAD952VE |
| Application | Cooling Water Pump and Thermostat Housing |
