Cylinder head gasket 270789
| No. | Part Name | Part Number | Qty | Description |
| 1 | Cylinder head | 3803039 | 6 | SN-2100287585, (422831) |
| 1 | Cylinder head | 3803287 | 6 | SN-2100287585, (479207) |
| 2 | Valve seat, intake | 467474 | 6 | Std |
| 2 | Valve seat, intake | 467590 | 6 | 0.20mm o.s |
| 3 | Valve seat, exhaust | 1545885 | 6 | O.S=0,20mm |
| 3 | Valve seat, exhaust | 1545886 | 6 | Std D |
| 4 | Valve guide, intake | 422320 | 6 | |
| 5 | Valve guide, intake | 11129092 | 6 | |
| 6 | Socket set | 270946 | 6 | |
| 7 | Sealing ring | 466405 | 6 | |
| 8 | Ring | 466420 | 6 | |
| 9 | Plug | 8194467 | 12 | |
| 10 | O-ring | 949762 | 12 | |
| 11 | Pin | 950543 | 12 | |
| 12 | Inlet valve, intake | 479204 | 6 | |
| 13 | Exhaust valve, exhaust | 467855 | 6 | |
| 14 | Valve spring | 467334 | 12 | Late type |
| 15 | Valve spring | 467335 | 12 | Late type |
| 16 | Valve cap | 478074 | 12 | |
| 17 | Valve spring washer, upper | 467506 | 12 | |
| 18 | Valve cotter | 468305 | 24 | |
| 19 | Bearing bracket | 422018 | 6 | |
| 20 | Flange screw | 422428 | 12 | |
| 21 | Rocker arm shaft | 422019 | 6 | |
| 22 | Cap plug | 946778 | 12 | |
| 23 | Pin | 950499 | 6 | |
| 24 | Rocker arm | 422063 | 12 | |
| 25 | Bushing | 422066 | 12 | |
| 26 | Ball stud | 422993 | 12 | |
| 27 | Hexagon nut | 940175 | 12 | |
| 28 | Washer | 941488 | 12 | |
| 29 | Retaining ring | 914459 | 12 | |
| 30 | Cylinder head gasket | 270789 | 6 | |
| 30 | Sealing ring | 422413 | 6 | D=11mm |
| 30 | Sealing ring | 422414 | 12 | D=32mm |
| 30 | Sealing ring | 422415 | 12 | D=18mm |
| 31 | Flange screw | 422086 | 24 | |
| 32 | Valve cover | 469431 | 6 | |
| 33 | Gasket | 424693 | 6 | |
| 34 | Hexagon screw | 940159 | 12 | |
| 35 | Washer | 955894 | 12 | |
| 36 | Valve cover | 469432 | 5 | |
| 37 | Valve cover, oil filling | 469457 | 1 | |
| 38 | Gasket | 424694 | 6 | |
| 39 | Hexagon screw | 955530 | 24 | |
| 40 | Spring washer | 941907 | 24 | |
| 41 | Gasket | 1275379 | 1 | |
| 42 | Oil filler cap | 421753 | 1 | |
| 43 | Cross recessed screw | 955126 | 3 | |
| 44 | Seal | 479260 | 6 | Included in gasket kit,decarbonizing 276035. |
| 45 | Plug | 941876 | 1 | |
| 46 | Gasket | 18666 | 1 | |
| 47 | De-carbonizing kit, decarbonizing | 276035 | 1 |
| Item | Part Name | Part No. |
| 30 | Cylinder head gasket 270789 | 270789 |
| Details | |
| Engine model | DH10A TAD1030G TAD1030GE TAD1030P TAD1030V TAD1031GE TAD1031GE, TAD1032GE TAD1032GE TD100CHC TD100CRC TD100G-87 TD100G-87, TAD1030V, TWD1031VE, TAD1030VE TD1010G, TWD1010G TD1030ME TD1030ME, TWD1030ME TD1030VE THD102KB THD102KD THD102KD, THD102KB TWD1030ME TWD1031VE |
| Application | Cylinder Head Cylinder Head: A Cylinder Head: B Repair Kits Repair Kits: A Repair Kits: B Repair Kits: C Repair Kits: TD100-87 Repair Kits: TID100-87 |
| Specification | |
| Descriptions | See group 10A |
