Volvo 20798186 Cylinder head gasket, cylinder head 20798186 Engine spare parts-Generator engine parts Mall

Cylinder head gasket, cylinder head 20798186

0 reviews Write a review

Qty

No.	Part Name	Part Number	Qty	Description
1	Cylinder head	3803974	1
2	Cap plug	20412745	5
3	Valve seat, intake	20849976	6
4	Insert, exhaust	20849979	6
5	Cap plug	20412733	5
6	Valve stem seal	20459855	12
7	Plug	20792165	1
8	Valve spring	20459851	12
9	Spring disc	20840747	12
10	Valve cotter	20459857	24
11	Thrust washer	20840807	12
12	Snap ring	20792103	12
13	Inlet valve	20798699	6
14	Exhaust valve	20798533	6
15	Cylinder head gasket, cylinder head	20798183	1	TH=1,26mm, One dot
15	Cylinder head gasket, cylinder head	20798186	1	TH=1,36mm, Two dots
15	Cylinder head gasket, cylinder head	20798191	1	TH=1,46mm, Three dots
16	Spring pin	20459839	2
17	Glow plug	20783049	6
18	Flange screw	20459838	19
19	Gasket	969011	2
20	Plug	20405716	1	M14
21	Adapter	20450683	1	EDC IV
22	Gasket	947628	1
23	Sensor, coolant temperature	20513340	1
24	Solenoid valve	20795296	1
25	Gasket kit	20873253	1
26	Hexagon nut	20845198	1
27	Bracket	20799047	1
28	Bracket	20799053	5
29	Bracket	20799056	1
30	Flange screw	20459837	7
31	Six point screw	993275	5
32	Pin	20790837	7
33	Rocker arm	20792878	6	Rocker arm for hydraulic valve push. AGR- Module.
34	Rocker arm	20792876	6
35	Adjusting screw	20816389	6
36	Hexagon nut	11700373	12
37	Adjusting screw	20913851	6
38	Washer	20794115	12
39	Module, rear	20799568	1
40	Module, front	20799570	1
41	Plug	20798864	1
42	Six point screw	20799085	6
43	Cap	20412590	1
44	Gasket, valve cover	20841035	1
45	Valve cover	20841027	1	Replaced by 21134620.
46	Flange screw	20412601	13
47	Filler cap	20412589	1
48	Gasket	20840801	1
49	Oil separator	20840827	1	Replaced by 20933359
50	Hexagon screw	20792158	6
51	Gasket	20859647	2
52	Plug	20798862	1

Item	Part Name	Part No.
15	Cylinder head gasket, cylinder head 20798186	20798186
