Exhaust valve 421017
| No. |
Part Name |
Part Number |
Qty |
Description |
| 1 |
Cylinder head |
3803031 |
2 |
(466769) |
| 2 |
Valve seat |
421011 |
6 |
Std D |
| 2 |
Valve seat |
421316 |
6 |
0.20mm o.s |
| 3 |
Valve seat |
466266 |
6 |
Std D |
| 3 |
Valve seat |
466307 |
6 |
0.20mm o.s |
| 4 |
Valve guide |
466386 |
12 |
|
| 5 |
Sealing ring |
469205 |
6 |
|
| 6 |
Sleeve |
466284 |
6 |
|
| 7 |
Expansion plug |
192426 |
4 |
|
| 8 |
Plug |
467367 |
4 |
|
| 9 |
Gasket |
469328 |
4 |
|
| 10 |
Plug |
466230 |
4 |
|
| 11 |
Gasket |
420166 |
4 |
|
| 12 |
Inlet valve |
421016 |
6 |
|
| 13 |
Exhaust valve |
421017 |
6 |
|
| 14 |
Compression spring |
421374 |
12 |
|
| 15 |
Washer |
421295 |
12 |
|
| 16 |
Valve cotter |
402418 |
24 |
|
| 17 |
Valve cap |
469365 |
12 |
(417133) |
| 18 |
Protecting ring |
469456 |
12 |
Replaced by 1pc 829493, 1pc 833521, 1pc 957181., (466932) |
| 19 |
Bearing bracket |
421416 |
6 |
|
| 20 |
Stud |
420270 |
4 |
|
| 21 |
Hexagon screw |
955540 |
8 |
MOXXXXX/105195- |
| 22 |
Spring washer |
942336 |
8 |
|
| 23 |
Shaft |
421019 |
2 |
|
| 24 |
Cap plug |
946778 |
4 |
|
| 25 |
Rocker arm |
422063 |
12 |
|
| 26 |
Bushing |
422066 |
12 |
|
| 27 |
Ball stud |
423058 |
12 |
|
| 28 |
Hexagon nut |
940175 |
12 |
|
| 29 |
Spring |
421173 |
4 |
|
| 30 |
Spring |
421172 |
4 |
|
| 31 |
Retaining ring |
914459 |
4 |
|
| 32 |
Cylinder head gasket |
275525 |
2 |
|
| 33 |
Sealing ring |
422413 |
2 |
D=11mm |
| 33 |
Sealing ring |
422414 |
12 |
D=32mm |
| 33 |
Sealing ring |
466421 |
16 |
D=16mm |
| 34 |
Flange screw |
421218 |
20 |
|
| 35 |
Flange screw |
466764 |
6 |
|
| 36 |
Cover |
421063 |
1 |
|
| 37 |
Cover |
421065 |
1 |
|
| 38 |
Cap nut |
424341 |
4 |
|
| 39 |
Sealing ring |
469846 |
4 |
|
| 40 |
Retaining ring |
914449 |
4 |
|
| 41 |
Gasket |
421066 |
2 |
|
| 42 |
Breather cap |
407173 |
1 |
|
| 42 |
Oil filler cap |
420292 |
1 |
|
| 43 |
Breather cap |
848261 |
2 |
For engine,40° inclanation., (844491) |
| 44 |
Gasket |
940096 |
1 |
|
| 45 |
Hose |
844508 |
2 |
For engine,40° inclanation. |
| 46 |
Hose clamp |
994559 |
2 |
|
| 47 |
Clamp |
943717 |
4 |
|
| 48 |
Hexagon screw |
955523 |
2 |
|
| Item |
Part Name |
Part No. |
| 13 |
Exhaust valve 421017 |
421017 |
| Details |
| Engine model |
TD70B |
| Application |
Cylinder Head: B |
Tags:
Exhaust valve,
Volvo Penta,
421017
