Fan 3827491
| No. | Part Name | Part Number | Qty | Description |
| 1 | Radiator | 20536948 | 1 | Replaced by radiator 20722448 |
| 2 | Charge air cooler | 3183748 | 1 | |
| 3 | Fan shroud | 3837478 | 1 | |
| 4 | Sealing strip | 3827817 | 1 | L=900mm |
| 5 | Bracket | 3835324 | 2 | |
| 6 | Flange screw | 965184 | 2 | |
| 7 | Flange lock nut | 948645 | 2 | |
| 8 | Plate | 1665309 | 2 | |
| 9 | Spacer | 1676648 | 4 | |
| 10 | Rubber cushion | 1665312 | 4 | |
| 11 | Flange screw | 965188 | 4 | |
| 12 | Flange nut | 971095 | 4 | Alt |
| 13 | Radiator casing | 3837474 | 1 | Right |
| 14 | Flange screw | 946470 | 2 | |
| 15 | Flange screw | 946470 | 4 | |
| 16 | Radiator bracket | 3588452 | 1 | |
| 17 | Bracket | 1676328 | 2 | |
| 18 | Flange screw | 946440 | 4 | |
| 19 | Rubber cushion | 1665322 | 2 | |
| 20 | Washer | 960142 | 2 | Replaced by 1 PC 843512,1 ST 191026. |
| 21 | Flange lock nut | 948645 | 2 | |
| 22 | Flange screw | 968893 | 2 | |
| 23 | Flange lock nut | 948645 | 2 | |
| 24 | Flange screw | 968842 | 2 | L=110mm |
| 25 | Flange lock nut | 948645 | 2 | |
| 26 | Hose clamp | 943480 | 4 | MO-XXXXX/98707., (951797) |
| 27 | Radiator hose | 3827266 | 1 | |
| 28 | Hose clamp | 994561 | 2 | |
| 29 | Hose | 3837251 | 1 | Expansion tank- water pump., L=550mm |
| 30 | Hose clamp | 994556 | 4 | |
| 31 | Rubber hose | 943367 | 1 | L=1700mm |
| 32 | Rubber hose | 943367 | 1 | L=1700mm |
| 33 | Hose | 192618 | 1 | L=1400mm |
| 34 | Hose clamp | 994556 | 2 | |
| 35 | Hose nipple | 980568 | 1 | Mounted in cylinder head. for air ventilation to the expansion tank. |
| 36 | Cable tie | 948211 | 1 | |
| 37 | Expansion tank | 1674916 | 1 | |
| 38 | Filler cap | 1674922 | 1 | |
| 39 | Pressure cap | 1674083 | 1 | |
| 40 | Flange screw | 946441 | 5 | |
| 41 | Flange lock nut | 948645 | 1 | |
| 42 | Cover | 3830539 | 1 | |
| 43 | Flange screw | 946440 | 8 | |
| 44 | Protecting casing | 3839262 | 1 | |
| 45 | Bracket | 3835505 | 1 | |
| 46 | Bracket | 3819733 | 1 | |
| 47 | Flange screw | 946173 | 7 | |
| 48 | Fan ring | 1664910 | 1 | |
| 49 | Fan hub | 3829538 | 1 | |
| 50 | Fan | 3827491 | 1 | Suction type |
| 51 | Fan guard | 3825490 | 2 | |
| 52 | Stud | 130204 | 6 | |
| 52 | Stud | 953001 | 6 | |
| 53 | Flange screw | 965216 | 12 | |
| 54 | Spacer sleeve | 807257 | 12 | |
| 55 | Pulley | 3807446 | 1 | Ratio 1:1,07 |
| 55 | Pulley | 3829958 | 1 | Ratio 1:0,99 |
| 56 | Bracket | 3826687 | 1 | |
| 57 | Flange screw | 965188 | 4 | |
| 58 | Flange screw | 973098 | 1 | |
| 59 | Flange screw | 946752 | 4 | |
| 60 | Fan hub | 21924453 | 1 | |
| 61 | V-ribbed belt | 3830066 | 1 | For 3829958 |
| 61 | V-ribbed belt | 70326595 | 1 | Ratio 1,08 |
| 62 | Charge air pipe | 3835864 | 1 | |
| 63 | Charge air hose | 1676199 | 1 | |
| 64 | V-clamp | 1676424 | 5 | |
| 65 | Charge air pipe | 3883225 | 1 | |
| 66 | Clutch | 3831190 | 1 | Early type |
| 67 | Flange screw | 946934 | 2 | |
| 68 | Flange screw | 965192 | 2 | |
| 69 | Half clamp | 1674206 | 1 | |
| 70 | Flange nut | 971096 | 2 | |
| 71 | Hose clamp | 865575 | 2 | |
| 72 | Charge air hose | 865127 | 1 | |
| 73 | Radiator protector | 3828184 | 1 | |
| 74 | Flange screw | 946173 | 4 | |
| 75 | Flange lock nut | 949278 | 4 | |
| 76 | Vibration damper | 866461 | 2 | |
| 77 | Screw | 941651 | 2 | |
| 78 | Emblem | 846118 | 1 | |
| 79 | Radiator hose | 3827265 | 1 | |
| 80 | Hose | 20487964 | 1 | |
| 81 | Flange screw | 946817 | 8 | |
| 82 | Flange nut | 971096 | 8 | |
| 83 | Flange lock nut | 971098 | 6 | |
| 84 | Charge air pipe | 1676665 | 1 | |
| 13A | Radiator casing | 3837475 | 1 | Left |
| Item | Part Name | Part No. |
| 50 | Fan 3827491 | 3827491 |
| Details | |
| Engine model | TAD1030V TAD1140VE, TAD1141VE, TAD1142VE TAD1150VE, TAD1151VE, TAD1152VE TAD1170VE, TAD1171VE, TAD1172VE TAD1250VE, TAD1251VE, TAD1252VE TAD1340VE, TAD1341VE, TAD1342VE, TAD1343VE, TAD1344VE, TAD1345VE, TAD1360VE, TAD1361VE, TAD1362VE, TAD1363VE, TAD1364VE, TAD1365VE TAD1351VE, TAD1352VE, TAD1353VE TAD1352VE TAD1360VE TAD1361VE TAD1363VE TAD1371VE, TAD1372VE, TAD1373VE, TAD1374VE, TAD1375VE TAD940VE, TAD941VE, TAD942VE, TAD943VE, TAD950VE, TAD951VE, TAD952VE TWD1240VE TWD740VE |
| Application | Fan Fan and Fan Ring, D=750mm. Suction & Pushing Fan and Fanring Radiator and Fan Radiator and Fan D=750mm Radiator and Fan. HD Radiator and Fan. Suction HD |
| Specification | |
| Descriptions | D=750mm Fan, suction type together with fan ring 1664910, mobile application., D=750mm For plastic fan, D=750mm For suction type of fan. Suction fan Suction fan, D=750mm Suction type Suction type., D=750mm |
