Fan 3828964
| No. | Part Name | Part Number | Qty | Description |
| 1 | Radiator | 3843761 | 1 | Replaced by 21146121 |
| 2 | Fan shroud | 3826684 | 1 | |
| 3 | Sealing strip | 3827816 | 2 | (3831141) |
| 4 | Flange screw | 967949 | 10 | |
| 5 | Flange screw | 946817 | 8 | |
| 6 | Flange nut | 971096 | 8 | |
| 7 | Radiator hose | 3830050 | 1 | For thrust fan. |
| 7 | Radiator hose | 3830795 | 1 | For suction type of fan. |
| 8 | Radiator hose | 3826677 | 1 | For thrust fan. |
| 8 | Radiator hose | 3827266 | 1 | |
| 9 | Hose clamp | 943480 | 4 | MO-XXXXX/98707., (951797) |
| 10 | Hose | 952973 | 1 | L = 110 MM |
| 11 | Hose clamp | 994561 | 2 | |
| 12 | Rubber hose | 943367 | 1 | L=1700mm |
| 13 | Rubber hose | 943367 | 1 | L=1700mm |
| 14 | Hose clamp | 993979 | 4 | |
| 15 | Expansion tank | 1674916 | 1 | |
| 16 | Spacer sleeve | 3830771 | 1 | |
| 17 | Spacer sleeve | 843028 | 1 | |
| 18 | Flange screw | 946471 | 3 | |
| 19 | Flange screw | 947790 | 1 | |
| 20 | Flange screw | 965220 | 1 | |
| 21 | Fan hub | 3829537 | 1 | |
| 22 | Stud | 130204 | 6 | |
| 23 | Flange lock nut | 971098 | 6 | |
| 24 | Fan | 3828963 | 1 | Suction fan, D=890mm |
| 24 | Fan | 3828964 | 1 | |
| 25 | Fan ring | 3827612 | 1 | |
| 26 | Flange screw | 946173 | 12 | |
| 27 | Protecting casing | 3839262 | 1 | |
| 28 | Flange screw | 946440 | 11 | |
| 29 | Bracket | 3826687 | 1 | |
| 30 | Flange screw | 973098 | 1 | |
| 31 | Flange screw | 965188 | 4 | |
| 32 | Fan hub | 21924453 | 1 | |
| 33 | Flange screw | 946752 | 4 | |
| 34 | Filler cap | 1674922 | 1 | |
| 35 | Pressure cap | 1674083 | 1 | |
| 36 | Cover | 3830539 | 1 | |
| 37 | Flange screw | 946440 | 1 | |
| 38 | Flange nut | 945408 | 1 | |
| 39 | Bracket | 3831494 | 1 | |
| 40 | Radiator protector | 3827871 | 1 | |
| 41 | Flange screw | 948217 | 6 | |
| 42 | Emblem | 846118 | 1 | |
| 43 | Screw | 941651 | 2 | |
| 44 | Fan guard | 3825490 | 2 | |
| 45 | Pulley | 3829957 | 1 | Ratio 0.93:1 |
| 45 | Pulley | 3829958 | 1 | Ratio 1:0,99 |
| 46 | V-ribbed belt | 3830066 | 1 | For 3829958 |
| 46 | V-ribbed belt | 3830067 | 1 | For 3829957 |
| 47 | Cable tie | 948211 | 8 | |
| 48 | Hose clamp | 994556 | 1 | |
| 49 | Hose | 192618 | 1 | L=1400mm |
| 50 | Hose nipple | 980568 | 1 | Mounted in cylinder head. for air ventilation to the expansion tank. |
| 51 | Spacer | 3832463 | 2 |
| Item | Part Name | Part No. |
| 24 | Fan 3828964 | 3828964 |
| Details | |
| Engine model | TAD1242GE TAD1630G, TAD1630GE TAD1630V TAD1631G, TAD1631GE TAD1640GE, TAD1641GE, TAD1642GE TAD1640GE, TAD1641GE, TAD1642GE, TAD1650GE, TAD1651GE TAD1641VE, TAD1642VE TAD1641VE, TAD1642VE, TAD1643VE, TAD1650VE, TAD1660VE, TAD1661VE, TAD1662VE TAD1641VE, TAD1642VE, TAD1643VE, TAD1650VE, TAD1660VE, TAD1661VE, TAD1662VE, TAD1640VE-B, TAD1641VE-B, TAD1642VE-B TAD1643VE-B TAD1650VE TAD1650VE-B, TAD1651VE TAD1660VE, TAD1661VE, TAD1662VE TAD1670VE, TAD1671VE, TAD1672VE TAD940GE TAD940GE, TAD941GE TAD940VE, TAD941VE, TAD942VE, TAD943VE, TAD950VE, TAD951VE, TAD952VE TAD941GE TWD1240VE TWD1630G TWD1630V |
| Application | Cooling system and components HD, SN-2016087664 Cooling system and components HD, SN2016087665- Fan Fan with Installation Components, pusher, SN-2016079647 Fan, SN2016079648- Radiator and Fan Radiator and Fan. Power Pac Radiator and Fan. Pusher Radiator and Fan. Pusher. 1, 09:1 Radiator and Plastic Fan Radiator and Plastic Fan, SN-2160048211 Radiator and Plastic Fan, SN2160048211- Radiator and Pushing Fan. SN-2016028724 |
| Specification | |
| Descriptions | D=890mm Plastic fan Pusher type Pusher type., D=890mm Pushing fan |
