Fan 843563
| No. | Part Name | Part Number | Qty | Description |
| 1 | Bracket | 11030668 | 1 | (4772126) |
| 2 | Pulley | 3829637 | 1 | (849932) |
| 2 | Pulley | 11030505 | 1 | D=140mm |
| 3 | Ball bearing | 1660115 | 1 | |
| 4 | Snap ring | 914532 | 1 | |
| 5 | Hexagon screw | 970959 | 1 | |
| 6 | Washer | 4772122 | 2 | |
| 7 | Washer | 947541 | 2 | |
| 8 | Hexagon nut | 971071 | 1 | |
| 9 | Stud | 17378 | 2 | L=170mm |
| 10 | Stud | 479972 | 1 | (924079) |
| 11 | Stud | 479973 | 1 | |
| 12 | Flange nut | 971095 | 4 | Alt |
| 13 | Anchorage | 4772116 | 1 | |
| 14 | Flange screw | 965216 | 4 | |
| 15 | Washer | 955894 | 4 | |
| 18 | V-belt | 966847 | 1 | L=2x1175mm |
| 18 | V-belt | 978740 | 1 | Alt L=2x1150mm |
| 20 | Fan hub | 787769 | 1 | Alt L=28mm |
| 20 | Hub | 848194 | 1 | L=43mm |
| 21 | Flange screw | 946173 | 4 | |
| 22 | Fan | 843517 | 1 | Åkerman spec. 867454., D70B spec. 867055, 867056, 867057 MOXXXXX/6622-. D70B spec. 867061, 867063, 867277. TD70B spec. 867065. D70B spec. 867059, 867260 alt. D70BK alt., D=620mm |
| 22 | Fan | 843563 | 1 | Spec. 867221., D70B spec. 867062, 867221, 867259, 867260, 867278. TD70B spec 867065 alt. D70BK alt., D=620mm |
| 23 | Flange screw | 945444 | 4 | |
| 24 | Spring washer | 941907 | 4 | |
| 25 | Spacer ring | 848379 | 1 | |
| 26 | Fan | 865790 | 1 | Alt |
| 27 | Flange screw | 946440 | 6 | |
| 28 | Flange screw | 945444 | 4 |
| Item | Part Name | Part No. |
| 22 | Fan 843563 | 843563 |
| Details | |
| Engine model | D100A D100B D100BRC, TD100ARC D120A D70B D70CRC, TD70CRC TD100A TD100CRC TD100G TD100G-85 TD100G-87 TD100GG TD100GG-85 TD100GG-87 TD100GP TD100GP-85 TD100HP-87 TD1010G, TWD1010G TD120A TD60A TD60B TD60D TD60D-83 TD610G, TWD610G TD610M, TD630ME, TWD630ME TD610V, TWD610V, TD630VE, TWD630VE TD61A TD61ACE TD61AG, TID61AG TD61AW TD70B TD70G TD70G-83 TD710G, TWD710G TD71A, TWD710V, TD730VE TD71AG TD730ME TID100K TID100K-87 TID100KG TID100KG-87 TID100KP TID100KP-87 TID60D TID60DG TID70G TWD610P, TWD710P |
| Application | Fan Fan and Installation Components Fan and Installation Components: A Fan and Installation Components: B Fan and Installation Components: C Fan SN-2071145377 Fan, Fan- and Belt Protection with Installation Comp., Early Pr Fan, Fan- and Belt Protection with Installation Comp., Late Pro FAN, FAN- AND BELT PROTECTION WITH INSTALLATION COMPONENTS Fan, Fan- and Belt Protection with Installation Components: A Fan, Fan- and Belt Protection with Installation Components: B Fan, Fan- and Belt Protection with Installation Components: C Fan, Fan-and Belt Guard with Installation Components Fan, Fan-and Belt Guard with Installation Components: A Fan, Fan-and Belt Guard with Installation Components: B Fan, Fan-and Belt Guard with Installation Components: C Fan, Fan-and Belt Protection with Inst.components, MO-XXXXX/33071: A Fan, Fan-and Belt Protection with Inst.components, MO-XXXXX/33071: B Fan, Fan-and Belt Protection with Installation Components Fan, Fan-and Belt Protection with Installation Components: A Fan, Fan-and Belt Protection with Installation Components: B Fan: A Fan: B Radiator 0,65sqm RADIATOR AND FAN WITH INSTALLATION COMPONENTS RADIATOR AND FAN WITH INSTALLATION COMPONENTS: A RADIATOR AND FAN WITH INSTALLATION COMPONENTS: B Radiator and Fan, 35°C Radiator and Fan, SN2100256097- Radiator and Fan, Tropic 45°C Radiator and Installation Components 35CG: A Radiator and Installation Components 35CG: B Radiator and Installation Components 35CG: C Radiator and Installation Components 35CG: TD100HPB87 Radiator and Installation Components: A Radiator and Installation Components: B |
| Specification | |
| Descriptions | Alt.d=620mm D70B spec. 867062, 867221, 867259, 867260, 867278. TD70B spec 867065 alt. D70BK alt. D=620mm D=620mm, 4 hole Pusher type, D=620mm Replaced by 1pc 4804105, 1pc 350578., D=620mm Spec. 867221., D70B spec. 867062, 867221, 867259, 867260, 867278. TD70B spec 867065 alt. D70BK alt., D=620mm SPEC.9969, 867113., D = 620 MM |
