Frame 845606
| No. |
Part Name |
Part Number |
Qty |
Description |
| 1 |
Frame |
845606 |
1 |
|
| 2 |
Bracket |
820510 |
2 |
D70B spec.867055 alt spec.867277.D70BK, TD70B |
| 3 |
Hexagon screw |
955564 |
4 |
|
| 3 |
Hexagon screw |
955568 |
4 |
For bracket 829839 with 8 holes., L=76mm |
| 4 |
Hexagon screw |
955346 |
8 |
D100B PP, TD100A PP |
| 5 |
Spring washer |
940280 |
16 |
|
| 6 |
Nut plate |
845904 |
4 |
D70B PP alt |
| 7 |
Engine bracket |
843068 |
2 |
Power Pack |
| 8 |
Hexagon screw |
955342 |
8 |
D100B PP, TD100A PP |
| 9 |
Hexagon screw |
955561 |
12 |
|
| 10 |
Spring washer |
940280 |
20 |
|
| 11 |
Nut plate |
845905 |
4 |
D100B PP, TD100A PP |
| 12 |
Spacer |
845600 |
2 |
|
| Item |
Part Name |
Part No. |
| 1 |
Frame 845606 |
845606 |
| Details |
| Engine model |
TD70G |
| Application |
Engine Suspension, Power Pack: A |
