Gasket 1543360
| No. | Part Name | Part Number | Qty | Description |
| 1 | Turbocharger | 848439 | 1 | |
| 1 | Turbocharger | 864592 | 1 | Spec 868172 |
| 2 | Gasket | 470939 | 1 | Included in gasket kit for connecting of turbocharger. |
| 3 | Stud | 468891 | 4 | |
| 4 | Hexagon nut | 191894 | 4 | |
| 5 | Spacer sleeve | 470467 | 4 | |
| 6 | Lock washer | 468219 | 4 | |
| 7 | Oil pressure pipe | 848686 | 1 | |
| 8 | Plane gasket | 420641 | 1 | |
| 9 | Hexagon screw | 955297 | 1 | |
| 10 | Hexagon screw | 940142 | 1 | ÅKERMAN. |
| 11 | Spring washer | 941907 | 2 | |
| 12 | Hollow screw | 942007 | 1 | (954394) |
| 13 | Gasket | 11998 | 1 | |
| 14 | Gasket | 942703 | 1 | |
| 15 | Clamp | 946834 | 1 | |
| 16 | Hexagon screw | 955534 | 1 | |
| 17 | Oil return pipe | 848685 | 1 | |
| 18 | Hexagon screw | 955297 | 2 | |
| 19 | Spring washer | 941907 | 2 | |
| 20 | Gasket | 1543360 | 1 | |
| 21 | Hose | 466328 | 1 | |
| 22 | Hose clamp | 994559 | 2 | |
| 23 | Nipple | 941875 | 1 | |
| 24 | Gasket, plug | 18677 | 1 | |
| 25 | Cross recessed screw | 950046 | 1 | |
| 26 | Washer | 955893 | 1 | |
| 27 | Bracket | 965560 | 1 | |
| 28 | Clamp | 952632 | 1 | Late type |
| 29 | Spring washer | 941906 | 1 | |
| 30 | Gasket kit | 876352 | 1 | See group 99 |
| 30 | Hexagon nut | 955825 | 1 | Late type |
| Item | Part Name | Part No. |
| 20 | Gasket 1543360 | 1543360 |
| Details | |
| Engine model | TAD121CHC TAD1230G TAD1230P TAD1230V TAD1231GE, TAD1232GE TAD1630G, TAD1630GE TAD1630P TAD1630V TAD1631G, TAD1631GE TD100CHC TD100CRC TD120HP-86 TD1210G TD121CHC TD121CRC TD121G TD121G-87 TD121GG TD121GG, TD121GGP TD121GG-86 TD121GP-87 TD164KAE TID121FG TID121K, TID121KG, TID121KP TID121K-87, TID121KG-87, TID121KGP, TID121KP-87, TID121KPB-87 TID121K-87, TID121KG-87, TID121KPB-87 TID121L-87, TID121LG, TID121LG-87, TID121LGP-87, TID121LP, TID121LP-87 TID121L-87, TID121LG-87, TID121LGP-87, TID121LP-87, TID121LPB-87 TID121LG, TID121LP TID162AG, TID162AGP, TID162AP, TID162APB TWD1210G TWD1210P, TWD1211P TWD1210P, TWD1211P, TWD1211G TWD1210V, TWD1211V TWD1211G TWD1230ME TWD1230VE TWD1230VE, TWD1231VE TWD1231VE TWD1620G TWD1620G, TWD1630G TWD1630G TWD1630P TWD1630V |
| Application | Induction and Exhaust System Induction and Exhaust System: A Induction and Exhaust System: B Repair Kits Repair Kits: A Repair Kits: B Repair Kits: C Repair Kits: D Turbo Turbo and Installation Components Turbo and Installation Components: A Turbo and Installation Components: B Turbo and Installation Components: C Turbo and Installation Components: TD120HP86 TURBO AND INSTALLATION COMPONENTS: TID121FP Turbo, High Mounted SN-2120147401 TURBO: 470109 TURBO: 470779 Turbo: 847827 Turbo: 848427 Turbocharger Turbocharger, Components Turbocharger, High Mounted Turbocharger, Low Mounted: B Turbocharger: A Turbocharger: B |
| Specification | |
| Descriptions | Included in gasket kit for connecting of turbocharger. Included in gasket kit. Included in turbo. Not for TAD1230G Not for TAD1231GE, TAD1232GE. |
