Gasket 1545244
| No. | Part Name | Part Number | Qty | Description |
| 1 | Water pump | 844379 | 1 | Alt.qty.depending on how many temp.sensors and thermoswitches that are mounted., For 827021. |
| 2 | Gasket | 423127 | 1 | |
| 3 | Hexagon screw | 955542 | 6 | |
| 4 | Hexagon screw | 940162 | 2 | MO-XXXXX/105194 |
| 5 | Spring washer | 942336 | 8 | |
| 6 | Spring pin | 951973 | 2 | |
| 7 | Thermostat housing | 1545161 | 1 | |
| 8 | Gasket | 1545244 | 1 | |
| 9 | Sealing ring | 1544710 | 1 | |
| 10 | Thermostat | 1544683 | 1 | 82° |
| 11 | Sealing ring | 1544410 | 1 | |
| 12 | O-ring | 925074 | 1 | |
| 13 | Plug | 960632 | 1 | |
| 14 | Gasket | 11998 | 1 | |
| 15 | Housing | 1545162 | 1 | |
| 16 | Hexagon screw | 942547 | 6 | |
| 18 | Flange | 843908 | 1 | |
| 19 | Plug | 952077 | 1 | |
| 20 | Connecting pipe | 847537 | 1 | |
| 21 | O-ring | 925255 | 1 | |
| 22 | Hexagon screw | 940135 | 3 | |
| 23 | Spring washer | 941907 | 3 | |
| 24 | Spring washer | 942336 | 6 | |
| 25 | Nipple | 192555 | 1 | SN-XXXXXXXXXX/262417 |
| 26 | Sealing ring | 469477 | 1 | Replaced by 842427, 842428, 842429, 842423, 411710., Late type (424345) |
| 27 | Hexagon screw | 940135 | 2 | |
| 28 | Spring washer | 941907 | 2 | |
| 29 | Gasket | 423138 | 1 | |
| 2A | Sealant | 1161231 | 1 | 304ml |
| 30 | Pipe elbow, pipe | 423137 | 1 | For turbo with rotor 842832., (822430) |
| 31 | Plug | 952077 | 1 | |
| 32 | Hexagon screw | 955537 | 1 | |
| 32 | Hexagon screw | 955540 | 1 | MOXXXXX/105195- |
| 33 | Spring washer | 942336 | 2 | |
| 35 | V-belt | 966398 | 2 | L=1325mm |
| 36 | Pulley, 2 grooves | 843599 | 1 | For turbo with rotor 842063. |
| 37 | Hexagon screw | 940186 | 4 | |
| 38 | Spring washer | 941907 | 4 | |
| 25A | Reduction nipple | 190130 | 1 |
| Item | Part Name | Part No. |
| 8 | Gasket 1545244 | 1545244 |
| Details | |
| Engine model | TD100G-85 TD100G-87 TD100GG-85 TD100GG-87 TD100HP-87 TD1010G, TWD1010G TID100K TID100K-87 TID100KG TID100KG-87 TID100KP-87 |
| Application | Repair Kits Repair Kits: TD100-87 Repair Kits: TID100-87 Thermostat and Water Pump with Installation Components Thermostat and Water Pump with Installation Components: A Thermostat and Water Pump with Installation Components: B Thermostat and Water Pump with Installation Components: C Thermostat and Water Pump with Installation Components: D Thermostat and Water Pump with Installation Components: TD100HPB87 Thermostat and Water Pump with Installation Components: TID100KGP87 Water Pump and Thermostat Housing |
