Gasket 862704
| No. | Part Name | Part Number | Qty | Description |
| 1 | Inlet manifold | 837560 | 1 | MO 65139/XXXXX- |
| 2 | Sealing ring | 469829 | 6 | Included in gasket kit. |
| 3 | Hexagon screw | 955529 | 12 | |
| 4 | Spring washer | 941907 | 12 | |
| 5 | Plug | 191026 | 1 | |
| 6 | Exhaust pipe | 846482 | 1 | |
| 7 | Plug | 467367 | 6 | |
| 8 | Gasket | 469328 | 6 | |
| 9 | Plug | 191026 | 5 | |
| 10 | Plug | 960634 | 1 | |
| 11 | Gasket | 947627 | 1 | |
| 12 | Gasket | 862704 | 6 | |
| 13 | Hexagon screw | 959797 | 10 | |
| 14 | Hexagon screw | 941251 | 1 | L=159mm |
| 15 | Bracket | 965535 | 1 | When double sheated fuel pipes not are mounted. |
| 16 | Spacer ring | 912130 | 1 | |
| 17 | Hexagon screw | 941251 | 1 | L=159mm |
| 18 | Bracket | 965535 | 1 | When double sheated fuel pipes not are mounted. |
| 19 | Spacer ring | 912130 | 1 | |
| 20 | Spring washer | 942336 | 12 | |
| 21 | Shut-off cock | 949918 | 2 | (82745) |
| 22 | Sealing ring | 846923 | 2 |
| Item | Part Name | Part No. |
| 12 | Gasket 862704 | 862704 |
| Details | |
| Engine model | TD100CHC TD100CRC |
| Application | Induction and Exhaust Pipe: A Induction and Exhaust Pipe: B Repair Kits: A Repair Kits: B |
