Gasket, plug 18677
| No. | Part Name | Part Number | Qty | Description |
| 0 | Gasket | 11994 | 5 | |
| 0 | Gasket | 11996 | 2 | |
| 0 | Gasket | 11998 | 3 | |
| 0 | Gasket | 18666 | 2 | |
| 0 | Gasket | 18671 | 19 | |
| 0 | Gasket, plug | 18677 | 5 | |
| 0 | Gasket | 18818 | 1 | |
| 0 | Deflector | 70913 | 1 | |
| 0 | Ball bearing | 181538 | 1 | |
| 0 | Ball bearing | 181670 | 1 | |
| 0 | Big-end bearing kit | 270099 | 6 | Std D |
| 0 | Big-end bearing kit | 270100 | 6 | 0.25mm u.s |
| 0 | Big-end bearing kit | 270101 | 6 | 0.50mm u.s |
| 0 | Big-end bearing kit | 270102 | 6 | 0.75mm u.s |
| 0 | Big-end bearing kit | 270103 | 6 | 1.00mm u.s |
| 0 | Big-end bearing kit | 270104 | 6 | 1.25mm u.s |
| 0 | Main bearing kit | 270438 | 7 | |
| 0 | Main bearing kit | 270439 | 7 | 0.25mm u.s |
| 0 | Main bearing kit | 270440 | 7 | 0.50mm u.s |
| 0 | Main bearing kit | 270441 | 7 | 0.75mm u.s |
| 0 | Main bearing kit | 270442 | 7 | 1.00mm u.s |
| 0 | Main bearing kit | 270443 | 7 | 1.25mm u.s |
| 0 | Cylinder liner kit | 275038 | 6 | |
| 0 | Piston ring kit | 275304 | 6 | |
| 0 | Gasket kit, INTAKE AND EXHAUST MANIFOLD | 275451 | 1 | |
| 0 | Gasket kit, recondition | 275531 | 1 | |
| 0 | Cylinder head gasket | 275551 | 6 | MO-19032/XXXXX- |
| 0 | Oil pump kit | 275570 | 1 | |
| 0 | Sealing ring kit | 275734 | 6 | |
| 0 | Thrust washer kit | 276758 | 1 | Std D |
| 0 | Thrust washer kit | 276759 | 1 | 0,10mm o.s |
| 0 | Thrust washer kit | 276760 | 1 | 0,20mm o.s |
| 0 | Thrust washer kit | 276761 | 1 | 0,30mm o.s |
| 0 | Gasket | 413619 | 1 | |
| 0 | Sealing ring | 416033 | 3 | |
| 0 | Gasket, pipe | 417333 | 1 | |
| 0 | Retaining ring | 417466 | 12 | |
| 0 | Sealing ring | 421158 | 1 | |
| 0 | Gasket | 421187 | 1 | |
| 0 | Wear ring | 421306 | 1 | |
| 0 | Gasket | 422025 | 1 | |
| 0 | Gasket | 422074 | 6 | |
| 0 | Gasket | 422130 | 1 | |
| 0 | Felt ring | 422145 | 1 | Repl early production marked: 5-4-3-2-1-A-B.If other marking is stamped 4PCS 829308 have to be used., Early type |
| 0 | Felt ring, cover | 422146 | 1 | |
| 0 | Shaft | 422148 | 1 | |
| 0 | Gasket, water pump | 422171 | 1 | |
| 0 | Rubber ring | 422174 | 6 | |
| 0 | Gudgeon pin | 422344 | 6 | Std |
| 0 | Gasket, pipe bend | 422409 | 1 | |
| 0 | Sealing ring | 422413 | 6 | D=11mm |
| 0 | Sealing ring | 422414 | 12 | D=32mm |
| 0 | Sealing ring | 422415 | 12 | D=18mm |
| 0 | O-ring | 422551 | 1 | D70B spec. 867221., Early type |
| 0 | Gasket | 422626 | 1 | |
| 0 | Gasket | 423054 | 1 | AQ130D, AQ130C MO15302/XXXX-. BB115A MO1401/XXXX-. |
| 0 | Sealing ring | 423123 | 1 | |
| 0 | Gasket | 423127 | 1 | |
| 0 | Gasket | 423129 | 1 | |
| 0 | Gasket | 423138 | 1 | |
| 0 | Sealing ring | 423139 | 6 | |
| 0 | Gasket | 423145 | 6 | |
| 0 | Gasket | 423146 | 6 | |
| 0 | Washer | 424133 | 1 | |
| 0 | Sealing ring | 424342 | 6 | |
| 0 | Gasket | 467409 | 3 | |
| 0 | Gasket | 468461 | 12 | |
| 0 | Gasket | 468463 | 1 | |
| 0 | Gasket | 468556 | 1 | |
| 0 | Gasket | 468557 | 1 | |
| 0 | Sealing ring | 469205 | 6 | |
| 0 | Gasket | 469328 | 6 | |
| 0 | Protecting ring | 469456 | 12 | Replaced by 1pc 829493, 1pc 833521, 1pc 957181., (466932) |
| 0 | Sealing ring | 469477 | 1 | Replaced by 842427, 842428, 842429, 842423, 411710., Late type (424345) |
| 0 | Sealing ring | 469481 | 1 | D70B spec. 867221., Early type (424334) |
| 0 | Sealing ring, pipe bend | 469482 | 1 | (424346) |
| 0 | Sealing ring | 469483 | 2 | (422581) |
| 0 | Gasket | 469484 | 1 | Repl by valve lifter 1542208 and push rod 1542207., See group 2B |
| 0 | Bushing | 470234 | 2 | (940359) |
| 0 | Gasket | 821853 | 1 | |
| 0 | Seal | 837626 | 6 | MO52087/XXXXX- |
| 0 | Repair kit, CIRCULATION PUMP | 875386 | 1 | |
| 0 | De-carbonizing kit, decarbonizing | 875537 | 1 | |
| 0 | Gasket | 907132 | 4 | |
| 0 | Woodruff key | 910115 | 1 | |
| 0 | Retaining ring | 914462 | 1 | |
| 0 | O-ring, bearing housing | 925054 | 1 | |
| 0 | O-ring | 925059 | 1 | AQ115A compression 8,4:1. |
| 0 | O-ring | 925060 | 3 | |
| 0 | O-ring | 925062 | 2 | |
| 0 | O-ring | 925069 | 1 | |
| 0 | Gasket | 940096 | 1 | |
| 0 | Sealing ring | 941580 | 1 | |
| 0 | Gasket | 942580 | 26 | |
| 0 | Gasket | 942703 | 1 | |
| 0 | Gasket, oil pipe | 946729 | 3 | |
| 0 | O-ring | 949656 | 2 | |
| 0 | Spring pin | 951969 | 1 | Spec. 867139. |
| 0 | Gasket | 957171 | 15 | |
| 0 | Gasket | 957173 | 2 | |
| 0 | Gasket | 957175 | 3 | |
| 0 | Roller bearing | 1542870 | 1 | (184437) |
| 0 | Spacer sleeve | 1542871 | 1 | (844281) |
| 0 | Sealing ring | 1545283 | 1 | (1542833) |
| Item | Part Name | Part No. |
| 0 | Gasket, plug 18677 | 18677 |
| Details | |
| Engine model | D100A, D100B, TD100A D100BRC D70B D70CHC D70CRC DH10A TAD1030G TAD1030GE TAD1030GE, TAD1031GE TAD1030GE, TAD1031GE, TAD1032GE TAD1030P TAD1030V TAD1031GE TAD1032GE TAD120BHC TAD120CHC TAD121CHC TAD1230G TAD1230G, TAD1231GE, TAD1232GE TAD1230P TAD1230P, TD121GP-87, TWD1210P, TWD1211P TAD1230V TAD1231GE, TAD1232GE TAD1240GE TAD1240GE, TAD1241GE, TAD1242GE TAD1241GE, TAD1242GE TAD1241VE, TAD1242VE TAD1241VE, TAD1242VE, TAD1250VE, TAD1251VE, TAD1252VE TAD1250VE, TAD1251VE, TAD1252VE TAD1340VE, TAD1341VE, TAD1342VE, TAD1343VE, TAD1344VE, TAD1345VE, TAD1360VE, TAD1361VE, TAD1362VE, TAD1363VE, TAD1364VE, TAD1365VE TAD1350VE TAD1360VE TAD1361VE TAD1363VE TAD1640GE TAD1641GE, TAD1642GE, TAD1650GE, TAD1651GE TAD1641VE, TAD1642VE, TAD1643VE TAD1643VE-B TAD1650VE TAD1650VE-B, TAD1651VE TAD1660VE, TAD1661VE, TAD1662VE, TAD1640VE-B, TAD1641VE-B, TAD1642VE-B TAD1670VE, TAD1671VE, TAD1672VE TAD540-42VE, TAD550-51VE, TAD540VE, TAD541VE, TAD542VE, TAD550VE, TAD551VE, TAD552VE TAD570VE, TAD571VE, TAD572VE TAD730G TAD730P TAD730V TAD740GE TAD741GE TAD840VE, TAD841VE, TAD842VE, TAD843VE, TAD851VE, TAD852VE, TAD853VE, TAD850-52VE, TAD840-43VE TAD870VE, TAD871VE, TAD872VE, TAD873VE TAD940VE, TAD941VE, TAD942VE, TAD943VE, TAD950VE, TAD951VE, TAD952VE TD100ARC TD100CHC TD100CRC TD100G TD100G, TD100G-85, TID100K TD100G-85 TD100G-87 TD100GG TD100GG-85 TD100GP TD100GP-85 TD1010G TD1010G, TWD1010G TD1030ME TD1030ME, TWD1030ME TD1030VE TD1030VE, TWD1031VE TD120BHC TD120BRC TD120C TD120G TD120GG TD120HP-86 TD120HPP TD1210G TD1210G, TWD1210G, TWD1211G TD121CHC TD121CRC TD121G TD121G-87 TD121G-87, TD121GG-87, TD121GGP-87, TD121GPB-87 TD121GG TD121GG, TD121GGP TD121GG-86 TD121GP-87 TD164KAE TD40A TD45B TD60A TD60B TD60D TD60D-83 TD60D-83, TID60D TD60D-83, TID60D, TID60DG TD610M, TD630ME, TWD630ME TD610M, TD630ME, TWD630ME, TD730ME, TWD730ME, TWD731ME TD610V, TD630VE, TWD630VE, TD640VE TD610V, TWD610V, TD630VE, TWD630VE, TD640VE TD640VE TD70B TD70CHC TD70CRC TD70G TD70G-83 TD710G TD710G, TWD710G TD71A TD71A, TD71AW, TID71A TD71A, TID71A, TD730VE, TWD731VE TD71A, TID71A, TWD710V, TD730VE, TWD731VE, TAD730V, TWD740VE TD730ME TD730ME, TWD730ME, TWD731ME TD730VE THD102KD, THD102KB TID100K TID100KG TID100KP TID120FG TID120HPP TID121FG TID121K, TID121KG, TID121KP TID121K, TID121KG, TID121KP, TID121KGP, TID121LG, TID121LGP, TID121LP TID121K-87, TID121KG-87, TID121KGP, TID121KP-87, TID121KPB-87 TID121K-87, TID121KG-87, TID121KGP, TID121KP-87, TID121KPB-87, TID121L-87, TID121LG-87, TID121LG UT-87, TID121LGP-87, TID121LP-87, TID121LPB-87 TID121K-87, TID121KG-87, TID121KPB-87 TID121L-87, TID121LG, TID121LG-87, TID121LGP-87, TID121LP, TID121LP-87 TID121L-87, TID121LG-87, TID121LGP-87, TID121LP-87, TID121LPB-87 TID121LG, TID121LP TID60D TID60DG TID70G TID71A TWD1010G TWD1030ME TWD1031VE TWD1210G TWD1210P, TWD1211P TWD1210P, TWD1211P, TWD1211G TWD1210V, TWD1211V TWD1210V, TWD1211V, TAD1230V TWD1211G TWD1230ME TWD1230VE TWD1230VE, TWD1231VE TWD1231VE TWD1240VE TWD1240VE, TAD1241VE, TAD1242VE, TAD1250VE, TAD1251VE, TAD1252VE TWD1643GE TWD1643GE, TWD1652GE, TWD1653GE, TWD1663GE TWD630ME TWD630VE TWD710G TWD710P TWD710V TWD730ME, TWD731ME TWD731VE TWD740GE TWD740GE, TAD740GE, TAD741GE TWD740VE |
| Application | By-pass Filter for Higher Oil Volume, Alternative Location. By-pass Filter, Alternative Location Contacts and Sensors: A Contacts and Sensors: B Cylinder Block Cylinder Block and Related Parts Cylinder Block and Related Parts: A Cylinder Block and Related Parts: B Cylinder Block: A Cylinder Block: B Cylinder Block: C Cylinder Block: D ELECTRICAL OIL BILGE PUMP AND INSTALLATION COMPONENTS Electrical Oil Bilge Pump and Installation Components: A Electrical Oil Bilge Pump and Installation Components: B Engine Heater, Separately Mounted Engine Heater, Separately Mounted: 2000W Engine Heater, Separately Mounted: 750W Governor, Air Compressor Governor, Air Compressor. 16mm Pipe Lubricating System Lubricating System, Angle of Inclination 10° Lubricating System, Angle of Inclination 40° LUBRICATING SYSTEM, ANGLE OF INCLINATION 40°: A LUBRICATING SYSTEM, ANGLE OF INCLINATION 40°: B LUBRICATING SYSTEM, STANDARD MODEL Lubricating System, Standard Model: A Lubricating System, Standard Model: B Lubricating System, standard: A Lubricating System, standard: B Lubricating System, standard: C Lubricating System, Vehicle Type Lubricating System: A Lubricating System: B Lubricating System: C Lubricating System: SN-2061097292 Lubricating System: SN2061097293- Oil Filter and Installation Components Oil Filter with Installation Components Oil Filter, Alternative Location Repair Kit Repair Kit: A Repair Kit: B Repair Kits Repair Kits, Repair Kits: A REPAIR KITS: B Repair Kits: C REPAIR KITS: D Repair Kits: TD100-87 Repair Kits: TID100-87 Timing Gear Casing and Gears TIMING GEAR CASING AND TIMING GEARS Timing Gear Housing Timing Gear Housing: A Timing Gear Housing: B Turbo and Installation Components Turbo and Installation Components, Low Mounted TURBO AND INSTALLATION COMPONENTS, LOW MOUNTED: A TURBO AND INSTALLATION COMPONENTS, LOW MOUNTED: B Turbo and Installation Components: A Turbo and Installation Components: B Turbo and Installation Components: C Turbo and Installation Components: TD120HP86 Turbo, High Mounted SN-2120147401 Turbo, High Mounted SN2120147402- Turbo, High Mounted SNXXXXXXXXXX/147402-, SN-XXXXXXXXXX/238056 Turbo, High Mounted, SNXXXXXXXXXX/238057-: A Turbo, High Mounted, SNXXXXXXXXXX/238057-: B Turbocharger Turbocharger, High Mounted Turbocharger, High Mounted: A Turbocharger, High Mounted: B Turbocharger, High Mounted: C Turbocharger: A Turbocharger: B Turbocharger: TD100-87 Water Pump and Thermostat Housing SN-41097153 Water Pump and Thermostat Housing SN-41134996 Water Pump and Thermostat Housing SN410971544- Water Pump and Thermostat Housing SN41134997- |
| Specification | |
| Descriptions | 7/8UNF Alt Included in gasket kit for connecting of turbocharger. Included in gasket kit. Included in sump 421026. Late type MO-17868 SN-8002/XXXXXX., (7/8'') Spec. 867821 Up to SN-8002/XXXXXX and from SN XXXXXXXXXX/30629-, (7/8'') |
