Governor 3126311
| No. |
Part Name |
Part Number |
Qty |
Description |
| 1 |
Compressor |
1626060 |
1 |
|
| 1 |
Compressor, exch |
3803405 |
1 |
|
| 2 |
Gear |
478777 |
1 |
|
| 3 |
O-ring |
975610 |
1 |
For engines without air compressor. |
| 4 |
Stud |
967951 |
3 |
|
| 5 |
Spring washer |
941911 |
3 |
|
| 6 |
Flange nut |
971097 |
3 |
|
| 7 |
T-nipple |
866161 |
2 |
|
| 8 |
Plug |
968060 |
2 |
|
| 9 |
Hose |
941522 |
1 |
(13799) L=45mm |
| 10 |
Hose clamp |
943472 |
4 |
|
| 12 |
Nipple |
963947 |
1 |
|
| 13 |
Gasket |
957173 |
1 |
|
| 14 |
Nipple |
946089 |
1 |
|
| 15 |
Hose assembly |
977651 |
1 |
|
| 16 |
Nipple |
1083943 |
1 |
New design |
| 17 |
Gasket |
947628 |
1 |
|
| 18 |
Air filter |
8152010 |
1 |
|
| 19 |
Gasket |
947628 |
1 |
|
| 1A |
Nut |
1698672 |
1 |
|
| 20 |
Reduction nipple |
978381 |
1 |
|
| 21 |
Nipple |
6781778 |
1 |
|
| 22 |
Fitting nut |
354145 |
6 |
|
| 23 |
Sleeve |
967810 |
6 |
|
| 25 |
Nipple |
354141 |
1 |
|
| 26 |
Hose assembly |
967736 |
1 |
|
| 27 |
T-nipple |
948891 |
1 |
|
| 28 |
Safety valve |
1591738 |
1 |
|
| 29 |
Gasket |
11996 |
1 |
|
| 30 |
Nipple |
966419 |
2 |
|
| 31 |
Reduction nipple |
966459 |
2 |
|
| 32 |
Governor |
3126311 |
1 |
|
| 9A |
Hose coupling |
849227 |
1 |
|
| 9B |
Rubber moulding |
471626 |
1 |
|
| 9C |
Bracket |
849397 |
1 |
|
| 9D |
Flange screw |
965175 |
1 |
|
| 11A |
Hose nipple |
961653 |
1 |
|
| Item |
Part Name |
Part No. |
| 32 |
Governor 3126311 |
3126311 |
| Details |
| Application |
Air Compressor &Wabco &704 |
