Governor 847605
| No. | Part Name | Part Number | Qty | Description |
| 1 | Stop dog | 845972 | 1 | (823480) |
| 2 | Charge regulator | 845973 | 1 | 24V later prod (640581) |
| 3 | Cable block | 842146 | 1 | |
| 4 | Clamp | 952625 | 1 | |
| 5 | Extension cable | 842209 | 1 | Alt |
| 6 | Governor | 847605 | 1 | (843547) 12V |
| 7 | Cross recessed screw | 956091 | 3 | |
| 8 | Screw | 950032 | 3 | |
| 9 | Washer | 955892 | 3 | |
| 10 | Vibration damper | 899709 | 3 | |
| 11 | Cross recessed screw | 956092 | 3 | (241793) |
| 12 | Spring washer | 941906 | 6 | |
| 13 | Bracket | 822252 | 1 | |
| 14 | Bracket | 822131 | 1 | Spec. 867061, 867062 |
| 15 | Spacer sleeve | 408519 | 4 | AQ115A MOXXXX/86909-., Repl by 1pc 840539 bracket (8 holes), 9PCS 941907 6PCS 9552 97, 2pcs 955298. |
| 16 | Spacer sleeve | 822255 | 2 | Replaced by 1pc 1578938., L=24mm |
| 17 | Hexagon screw | 955525 | 4 | |
| 18 | Hexagon screw | 940161 | 2 | For engine with 40° angle of inclination, L=45mm |
| 18 | Hexagon screw | 955524 | 2 | Used on crankshaft 829999. |
| 19 | Spring washer | 941907 | 4 |
| Item | Part Name | Part No. |
| 6 | Governor 847605 | 847605 |
| Details | |
| Engine model | D42A D70B, TD70B |
| Application | Charging Relay and Installation Components ELECTRICAL SYSTEM AND INSTRUMENT |
| Specification | |
| Descriptions | (843547) 12V |
