Grommet 881520
| No. | Part Name | Part Number | Qty | Description |
| 1 | Alternator | 827349 | 1 | 28V 25A,later prod |
| 1 | Alternator | 847561 | 1 | 28V 30A |
| 2 | Hexagon screw | 955699 | 1 | |
| 3 | Spring washer | 941909 | 1 | AQ170B MOXXXX/87713-., BB170B MOXXXX/89353-. |
| 4 | Tensioner | 837445 | 1 | AQ200D MO-11576, AQ225D MO-11736, AQ260A MO-11506, AQ290A MO-12259 |
| 5 | Hexagon screw | 940161 | 1 | For engine with 40° angle of inclination, L=45mm |
| 6 | Washer | 191172 | 1 | Spec.867054, 867221. |
| 7 | Lock nut | 950353 | 1 | |
| 8 | Alternator bracket | 837441 | 1 | |
| 9 | V-belt | 958301 | 1 | Replaced by 837000 and 1pc 898683., L=775mm |
| 10 | Pulley | 820459 | 1 | Replaced by 1pc 841768. |
| 12 | Sealing ring | 837724 | 1 | |
| 13 | Cross recessed screw | 956061 | 3 | D70B spec. 867055, 867060. TD70B spec. 867066. |
| 14 | Spring washer | 941904 | 3 | |
| 15 | Cover | 836132 | 1 | |
| 16 | Cross recessed screw | 956065 | 3 | |
| 17 | Spring washer | 941904 | 3 | |
| 18 | Housing | 836138 | 1 | |
| 19 | Hex. socket screw | 940326 | 3 | |
| 20 | Spring washer | 941906 | 3 | |
| 21 | Attaching ring | 836477 | 1 | |
| 22 | Hexagon screw | 955253 | 2 | |
| 23 | Spring washer | 941905 | 2 | Replaced by 1306630, AQ125A USA MO-7545816/XXXX. AQ125A MO-7546500/XXXX. |
| 24 | Grommet | 822327 | 1 | |
| 24 | Grommet | 881192 | 1 | |
| 25 | Grommet | 881193 | 1 | Replaced by 1 alterator 841765 and 1 cable unit 841822. |
| 25 | Grommet | 881520 | 1 |
| Item | Part Name | Part No. |
| 25 | Grommet 881520 | 881520 |
| Details | |
| Engine model | D100B, TD100A D120A D70B TD120A |
| Application | Alternator and Installation Components, Classed Engine: A Alternator and Installation Components, Classed Engine: B Alternator and Installation Components, Spec 867108, 867153 Alternator and Installation Components, Spec.867117 Alt |
| Specification | |
| Descriptions | MOXXXXX/18627- |
