Gudgeon pin 421302
| No. | Part Name | Part Number | Qty | Description |
| 1 | Cylinder liner kit | 875676 | 6 | |
| 2 | Sealing ring kit | 271160 | 6 | (275735) |
| 3 | Piston ring kit | 271117 | 6 | (275375) |
| 4 | Gudgeon pin | 421033 | 6 | Std D |
| 4 | Gudgeon pin | 421300 | 6 | 0.05mm o.s |
| 4 | Gudgeon pin | 421302 | 6 | 0.20mm o.s |
| 5 | Snap ring | 914525 | 12 | |
| 6 | Connecting rod | 843678 | 6 | |
| 7 | Bushing | 471364 | 6 | (466454) |
| 8 | Connecting rod bolt | 420126 | 12 | |
| 9 | Hexagon screw | 944710 | 6 | |
| 10 | Crankshaft | 842376 | 1 | |
| 10 | Crankshaft | 847998 | 1 | |
| 11 | Woodruff key | 422253 | 1 | |
| 12 | Crankshaft gear | 421080 | 1 | |
| 13 | Oil deflector | 420172 | 1 | |
| 14 | Hub | 421400 | 1 | |
| 15 | Washer | 420124 | 1 | |
| 16 | Flange screw | 1545479 | 1 | (417464) |
| 17 | Absorber | 421401 | 1 | |
| 18 | Hexagon screw | 955548 | 6 | |
| 19 | Big-end bearing kit | 270115 | 6 | Std D |
| 19 | Big-end bearing kit | 270116 | 6 | 0,25mm u.s |
| 19 | Big-end bearing kit | 270117 | 6 | 0,50mm u.s |
| 19 | Big-end bearing kit | 270118 | 6 | 0,75mm u.s |
| 19 | Big-end bearing kit | 270119 | 6 | 1,00mm u.s |
| 19 | Big-end bearing kit | 270120 | 6 | 1,25mm u.s |
| 21 | Main bearing kit | 270432 | 7 | STD D |
| 21 | Main bearing kit | 270433 | 7 | 0.25 MM U.S |
| 21 | Main bearing kit | 270434 | 7 | 0.50 MM U.S |
| 21 | Main bearing kit | 270435 | 7 | 0.75 MM U.S |
| 21 | Main bearing kit | 270436 | 7 | 1.00 MM U.S |
| 21 | Main bearing kit | 270437 | 7 | 1.25 MM U.S |
| 22 | Thrust washer kit | 276754 | 1 | STD D |
| 22 | Thrust washer kit | 276755 | 1 | 0.1 MM O.S |
| 22 | Thrust washer kit | 276756 | 1 | 0.2 MM O.S |
| 22 | Thrust washer kit | 276757 | 1 | 0.3 MM O.S |
| 23 | Flywheel | 842761 | 1 | Repl by 848350 |
| 23 | Flywheel | 845676 | 1 | When air starter is mounted. |
| 23 | Flywheel | 848350 | 1 | |
| 24 | Gear ring | 420067 | 1 | MO84522/XXXX-MO84530.MO84652/XXXXX-.engine without air starting motor. |
| 25 | Pin | 950677 | 1 | |
| 26 | Washer | 467773 | 6 | |
| 27 | Adjusting washer | 466114 | 1 | TH=0.20mm |
| 27 | Adjusting washer | 466183 | 1 | TH=0.30mm |
| 27 | Adjusting washer | 466184 | 1 | TH=0.50mm |
| 28 | Pulley | 823595 | 1 | 2-Groove |
| 29 | Hexagon screw | 955551 | 6 | D70B spec. 867054, 867055, 867061, 867062, 867063, 867132, TD70B spec. 867065. |
| Item | Part Name | Part No. |
| 4 | Gudgeon pin 421302 | 421302 |
| Details | |
| Engine model | D70B D70CHC D70CRC TD70B TD70CHC TD70CRC TD70G TD70G-83 TID70G |
| Application | Crankshaft and Related Parts Crankshaft and Related Parts: A Crankshaft and Related Parts: B Crankshaft and Related Parts: C Crankshaft and Related Parts: D |
| Specification | |
| Descriptions | 0,20mm o.s 0.20mm o.s |
Related Products
Tags: Gudgeon pin, Volvo Penta, 421302
