Guide ring 828803
| No. |
Part Name |
Part Number |
Qty |
Description |
| 1 |
Instrument panel |
848071 |
1 |
|
| 2 |
Instrument panel |
860182 |
1 |
(858647) |
| 3 |
Tachometer |
828600 |
1 |
|
| 4 |
Attaching ring |
828558 |
1 |
|
| 5 |
Front ring |
858644 |
1 |
For 872040., D=95mm |
| 6 |
Bulb socket |
808175 |
2 |
|
| 7 |
Bulb |
182059 |
2 |
|
| 8 |
Hour counter |
828615 |
1 |
|
| 9 |
Thermometer |
863933 |
1 |
(828613) |
| 9 |
Manometer |
863935 |
1 |
(828619) |
| 10 |
Bulb socket |
863945 |
2 |
For 873625,873624,873664 |
| 11 |
Bulb |
863947 |
2 |
24V 1, 2W, W2x4,6d |
| 12 |
Front ring |
858643 |
3 |
(828542) |
| 13 |
Guide ring |
828803 |
3 |
|
| 14 |
Starter switch |
828778 |
1 |
Repl by 864277 |
| 15 |
Key |
828676 |
2 |
State key code when oredering |
| 16 |
Round nut |
1581184 |
1 |
|
| 17 |
Starter switch |
864277 |
1 |
Diode 1624694 should be used on engines with stop solenoid, energized to run. |
| 18 |
Marking label |
860086 |
1 |
|
| 19 |
Key |
859953 |
2 |
|
| 20 |
Plastic nut |
859955 |
1 |
|
| 21 |
Diode |
1578857 |
1 |
|
| 22 |
Buzzer |
828587 |
1 |
|
| 23 |
Toggle switch |
828584 |
1 |
|
| 23 |
Toggle switch |
828585 |
1 |
|
| 24 |
Nut |
828586 |
2 |
|
| 25 |
Symbol strip |
858645 |
1 |
(828560) |
| 26 |
Bulb |
828818 |
4 |
24V 2WBA7S |
| 27 |
Reflector |
828784 |
1 |
|
| 28 |
Electronic unit |
828783 |
1 |
|
| 29 |
Cross recessed screw |
941615 |
2 |
|
| 30 |
Spring washer |
941904 |
2 |
|
| 31 |
Screw |
828647 |
4 |
|
| 32 |
Cross recessed screw |
949947 |
1 |
Alt |
| 33 |
Spring washer |
941904 |
1 |
|
| 35 |
Protecting casing |
858795 |
1 |
|
| Item |
Part Name |
Part No. |
| 13 |
Guide ring 828803 |
828803 |
| Details |
| Engine model |
TID121FG |
| Application |
Instrument Panel |
