Hand pump 76703
| No. | Part Name | Part Number | Qty | Description |
| 3 | O-ring | 240270 | 1 | |
| 4 | Pump piston | 240548 | 1 | D=21,989-21,994mm |
| 5 | Push rod | 243374 | 1 | D=4,993-4,998mm |
| 6 | Spring | 76699 | 1 | |
| 7 | Plug | 6644428 | 1 | |
| 8 | Gasket | 18844 | 1 | |
| 9 | Cam follower | 240074 | 1 | |
| 10 | Roller | 240075 | 1 | |
| 11 | Lifting arm shaft | 240076 | 1 | |
| 12 | Cube | 240077 | 2 | |
| 13 | Spring ring | 238368 | 1 | |
| 14 | Valve | 243136 | 2 | |
| 15 | Compression spring | 76706 | 2 | |
| 16 | Plug | 25278 | 1 | |
| 17 | Gasket | 240572 | 2 | |
| 19 | Cover | 76707 | 1 | |
| 20 | Hollow screw | 25167 | 1 | |
| 21 | Gasket | 18838 | 2 | |
| 22 | Filter insert | 25282 | 1 | |
| 23 | Reservoir | 25283 | 1 | Alt 76708 |
| 24 | Gasket | 25284 | 1 | |
| 25 | Spring | 25285 | 1 | |
| 26 | Retaining clamp | 25288 | 1 | |
| 27 | Clamping nut | 240545 | 1 | |
| 28 | Tensioning screw | 25287 | 1 | |
| 29 | Hand pump | 76703 | 1 | Alt 843435 |
| 29 | Reservoir | 76708 | 1 | Spec version alt 25283 |
| 29 | Hand pump | 843435 | 1 | Class alt 76703 |
| Item | Part Name | Part No. |
| 29 | Hand pump 76703 | 76703 |
| Details | |
| Application | Fuel Feed Pump Fuel Feed Pump: 1699140 Fuel Feed Pump: 240072 Fuel Feed Pump: 242072 Fuel Feed Pump: 243083 Fuel Feed Pump: 244391 |
| Specification | |
| Descriptions | Alt 843435 |
