Hexagon screw 192058
| No. | Part Name | Part Number | Qty | Description |
| 1 | Inlet manifold | 820831 | 1 | |
| 2 | Rubber ring | 423174 | 6 | |
| 3 | Hexagon screw | 955529 | 12 | |
| 4 | Spring washer | 941907 | 12 | |
| 5 | Exhaust pipe | 824128 | 1 | |
| 6 | Plug | 467367 | 12 | |
| 7 | Gasket | 469328 | 12 | |
| 8 | Plug | 191086 | 1 | |
| 9 | Gasket | 190957 | 1 | |
| 10 | Gasket | 468647 | 6 | |
| 11 | Sealing ring | 822575 | 6 | |
| 12 | Hexagon screw | 942547 | 5 | |
| 13 | Hexagon screw | 192058 | 1 | |
| 14 | Hexagon screw | 941252 | 6 | (959800) |
| 15 | Spring washer | 942336 | 12 | |
| 16 | Shut-off cock | 82745 | 2 | |
| 17 | Bracket | 822546 | 1 | |
| 19 | Exhaust hose | 820900 | 1 | |
| 20 | Flange | 820915 | 2 | |
| 21 | Gasket | 807578 | 2 | |
| 22 | Hexagon screw | 955592 | 8 | |
| 23 | Spring washer | 941912 | 8 | |
| 24 | Hexagon nut | 955829 | 8 | Pusher type, For tropic radiator |
| 30 | Radiator hose | 470464 | 1 | (468216) |
| 31 | Hose clamp | 943480 | 2 | MO-XXXXX/98707., (951797) |
| 32 | End cover | 822593 | 1 | |
| 33 | Gasket | 822554 | 1 | |
| 34 | Sealing ring | 822575 | 1 | |
| 35 | Hexagon screw | 940115 | 3 | |
| 35 | Hexagon screw | 955535 | 2 | |
| 35 | Hexagon screw | 955539 | 1 | |
| 36 | Spring washer | 942336 | 6 | |
| 37 | Silencer | 836257 | 1 |
| Item | Part Name | Part No. |
| 13 | Hexagon screw 192058 | 192058 |
| Details | |
| Engine model | D120A TAD120AHC TAD120BHC TAD120CHC TAD121CHC TD120A TD120AHC TD120ARC TD120BHC TD120BRC TD121CHC TD121CRC |
| Application | Induction and Exhaust Manifold with Installation Components Induction and Exhaust Manifold with Installation Components: A Induction and Exhaust Manifold with Installation Components: B Induction and Exhaust Manifold with Installation Components: C Induction and Exhaust Manifold with Installation Components: D Induction and Exhaust Manifold: A Induction and Exhaust Manifold: B Induction- and Exhaust Manifold, Classed Engine: A Induction- and Exhaust Manifold, Classed Engine: B |
| Specification | |
| Descriptions | D70B spec. 867055, 867060. TD70B spec. 867066., L=152mm L=152mm other fuel pipes is mounted, L=152mm Spec. 867054, 867057 MO-XXXXX/6621, 867132. D70BK alt., L=152mm When double sheated fuel pipes are mounted., L=152mm |
